CHAPTER 7 RECEIPT MODE (INTERFACE COMMANDS)
B-EP Series
7-4
7.3 COMMANDS RELATED TO SETTING
7.3.1 MODE SELECT COMMAND [ESC] M
Function Changes the print mode.
Format [ESC] M; a(,b) [LF] [NUL]
Term a: Print mode designation
76 5 4 3210
* Table 1 Print mode
HEX Mode
How to deal with the received data after an error is cleared
30H LABEL Discards
31H RECEIPT Discards
32H RECEIPT1 Continues printing
34H ESC/POS Continues printing
41H TPCL Continues printing
42H TPCL1 Continues printing
b: Print position detection feed (Omissible. If omitted, the print position detection
feed is not performed.)
0: When the mode change from RECEIPT, RECEIPT1 or ESC/POS to LABEL,
TPCL or TPCL1 is requested, a print position detection feed is not performed
after the mode is changed.
1: When the mode change from RECEIPT, RECEIPT1 or ESC/POS to LABEL,
TPCL or TPCL1 is requested, a print position detection feed is performed after
the mode is changed.
Explanation (1) There are 4 types of the print mode: “LABEL”, “RECEIPT,” “TPCL” and
“ESC/POS.”
(2) “Automatic status response in IrDA: IrCOMM or USB” is the function for the
specifications which do not allow the printer to spontaneously send the status
through IrDA; IrCOMM or USB. This function enables the printer to forcefully send
the status to the host, if the link between the printer and the host is established.
However, if the link between the printer and the host is not established upon the
status transmission, the printer cannot send the status. Therefore, the status is
discarded. (In the next connection to the host, the printer does not send the
status to the host.)
Print mode (Bit 0 to Bit 6 * See Table 1.)
Automatic status response in IrDA: IrCOMM or USB
0: Not performed
1: Performed
To Next Page
