Page #588 background imageLoading...
Page #588 background image
CHAPTER 8 ESC/POS MODE (INTERFACE COMMANDS)
B-EP Series
8-61
8.10.42 PAGE MODE ABSOLUTE POSITION SET COMMAND [GS] $
Function Specifies an absolute position in the vertical direction in page mode.
Format [GS] $nLnH
Term ASCII: GS $
Hex: 1Dh 24h
[Parameter]
nL: Specifying absolute position in the vertical direction in page mode (low order)
0 nL 255 (00h nL FFh)
nH: Specifying absolute position in the vertical direction in page mode (high order)
0 nH 255 (00h nH FFh)
Default value
Explanation (1) An absolute position of the data expansion starting position in the vertical direction
in page mode is specified with reference to the starting position. The next data
expansion starting position is shifted (nL + nH × 256) dots away from the current
position in the vertical direction.
(2) This command is ignored except when page mode is selected.
(3) An absolute position in the vertical direction out of the specified print area is
ignored.
(4) A starting position, which is a reference to an absolute position, is specified in the
Page Mode Print Direction Set Command ([ESC] T).
Reference Absolute Position Set Command ([ESC] $)
Page Mode Print Direction Set Command ([ESC] T)
Page Mode Print Area Set Command ([ESC] W)
Relative Position Set Command ([ESC] \)
Page Mode Relative Position in Vertical Direction Set Command ([GS] \)
