CHAPTER 2 OUTLINE OF SPECIFICATIONS
B-EP Series
2-6
2.18 LCD
Mark + (5 x 7 dots) x 16 characters
2.19 SPEAKER
On-board beeper
Volume adjustment function
2.20 ISSUE MODE
Strip issue (with label present sensor)
Batch issue
2.21 PAPER
B-EP2DL B-EP4DL
Label width 13 to 55 mm 47 to 112 mm
Label-to-label gap 3 to 7 mm 3 to 7 mm
Black mark length 3 to 7 mm 3 to 7 mm
Backing paper width 16 to 58 mm 50 to 115 mm
Receipt paper width 16 to 58 mm 50 to 115 mm
To Next Page
