CHAPTER 5 TPCL MODE (INTERFACE COMMANDS)
B-EP Series
5-10
Examples (1) Label
(2) Tag
Refer to • Image Buffer Clear Command ([ESC]C)
[ESC] D0518, 0760, 0468, 0820 [LF] [NUL]
[ESC] T20C40 [LF] [NUL]
51.8 mm
46.8 mm
76.0 mm
82.0 mm
Backing pape
Label
Effective print area
[ESC ]D0772, 0996, 0722 [LF] [NUL]
[ESC] T10C40 [LF] [NUL]
77.2 mm
72.2 mm
99.6 mm
Effective print area
Tag
Black mark
(Printed on the
back of receipt)
To Next Page
