CHAPTER 5 TPCL MODE (INTERFACE COMMANDS)
B-EP Series
5-18
Examples
Strip issue
[ESC] AX; +010, +020, +00 [LF] [NUL]
[ESC] T20D40 [LF] [NUL]
1.0 mm 3.0 mm
A
B C
1.0 mm
Paper feed
direction
A
B C
z
Fine adjust the strip
position by +2.0 mm.
z
Fine adjust the print
position by +1.0 mm.
