CHAPTER 5 TPCL MODE (INTERFACE COMMANDS)
B-EP Series
5-21
Notes
(1) The set fine adjustment value for print density and the head output division designation
are backed up in memory (retained even if the power is turned off).
(2) The fine adjustment values changed by the Print Density Fine Adjust Command in the
TPCL mode, are also effective in the LABEL, RECEIPT or ESC/POS mode.
(3) When the head output division designation is omitted, the backed up value in memory is
used.
(4) When print density fine adjustment is selected in the SYSTEM mode (through key
operations on the printer), the fine adjustment value is a sum of the value in the fine
adjustment command and the system mode fine adjustment value. Note that the
maximum fine adjustment value is ± 30.0 mm
Examples
To set the density to - 2:
[ESC] AY; -02, 1 [LF] [NUL]
To set the density to + 3:
[ESC] AY; +03, 1 [LF] [NUL]
