CHAPTER 5 TPCL-LE MODE (INTERFACE COMMANDS)
B-EP Series
5-76
(9) Length of guard bar
The length of guard bar is valid only when the type of barcode is WPC.
It is ignored in all other cases.
(10) Numerals under bars
Numerals are/are not provided under bars according to the parameter for print/non print
of numerals under bars. The numerals under bars to be printed vary according to the
type of barcode.
The font of numerals under bars is OCR-B. These numerals are enlarged or reduced
only horizontally according to the width of the barcode. When they are drawn vertically,
no enlargement or reduction is applied.
[Drawing positions of numerals under bars]
c JAN and EAN
(Example) EAN13 + 2 digits
(Example) EAN8
Height of barcode
Length of guard bar
