CHAPTER 5 TPCL-LE MODE (INTERFACE COMMANDS)
B-EP Series
5-123
(7) Rotational angle of two-dimensional code
0° 90° 180° 270°
(8) Height of two-dimensional code
(9) Data string to be printed
Drawing data can be programmed by designating the number of digits after the symbol
“=.” The maximum number of digits to be printed is 366. (However, the number of
digits of data should be limited so the two-dimensional code can be printed within the 2-
inch head width.)
* 1 2 3 4 5 *
* 1 2 3 4 5 *
* 1 2 3 4 5 *
Height
Height
Point of origin
To Next Page
