CHAPTER 5 TPCL-LE MODE (INTERFACE COMMANDS)
B-EP Series
5-134
Notes
(1) More than one Two-dimensional Code Format Command can be connected when
transmitted.
[ESC] XB01; 0100, 0150, 3, 1, 02, 02, 06, 06, 02, 0, 0150 [LF]
B02; 0350, 0150, 3, 1, 02, 02, 06, 06, 02, 0, 0150 [LF] [NUL]
(2) When the drawing data is changed per label issue during printing, the field of the drawing
data for the previous label is automatically cleared using the two-dimensional code
number, then the next drawing data is printed. Therefore, the two-dimensional code
number which differs according to the drawing fields should be designated.
(3) Since the automatic field clear is not performed between the Clear Command ([ESC] C)
and Issue Command ([ESC] XS), the fixed data may be drawn using the same two-
dimensional code number. In this case, the Format Command and Data Command
should be sent alternately. (After the Issue Command is sent, the fields with the same
two-dimensional code number are automatically cleared until the Clear Command is
sent.)
(4) The link field designation is cleared by omitting the link field designation using the same
two-dimensional code No. and reformatting data. The link field designation can be also
cleared by the Image Buffer Clear Command.
(5) A print data string and link field No. cannot be programmed at the same time.
Refer to • Bit Map Font Format Command ([ESC] PC)
• Outline Font Format Command ([ESC] PV)
• Barcode/Two-dimensional Code Data Command ([ESC] RB)
To Next Page
