CHAPTER 5 TPCL-LE MODE (INTERFACE COMMANDS)
B-EP Series
5-162
Explanation
(1) When any data other than numerics is included in the data string of zip code (mode 2),
zip code extension, class of service, or country code, a MaxiCode is not drawn.
(2) If the message data is less than 84 digits when mode 2 or 3 is selected, the printer adds
one digit of CR (000000) at the end of the data, and the remaining digits will be filled with
FSs (011100). When message data exceeding 84 digits is received, the excess data will
be discarded before drawing a MaxiCode.
(3) If the message data is less than 93 digits (9 digits + 84 digits) when mode 4 or 6 is
selected, the printer adds one digit of CR (000000) at the end of the data, and the
remaining digits will be filled with FSs (011100). When message data exceeding 93
digits is received, the excess data will be discarded before drawing a MaxiCode.
(4) Mode 6 should not be used for usual operation since it is used for scanner programming.
(5) When “TYPE2: Special specification” is set for MaxiCode specification setting in the
SYSTEM mode and when Mode 2 is selected, the country code must be 840.
Otherwise, a MaxiCode will not be drawn.
(6) When “TYPE2: Special specification” is set for MaxiCode specification setting in the
SYSTEM mode and when Mode 3 is selected, the country code must be other than 840.
Otherwise, a MaxiCode will not be drawn.
To Next Page
