CHAPTER 5 TPCL-LE MODE (INTERFACE COMMANDS)
B-EP
Series
5-173
Example
Shift JIS 8140H to 83DFH:
0
1
23456789
A
B
C
D
E
F
8140
:
81F0
:
8240
:
82F0
:
8340
:
83D0
[ESC] XE; 8140, 00BD, 8240,
00B7, 8340, 00BD [LF] [NUL]
Character data is present.
Character data is not present.
342
344
Table of Contents
TABLE OF CONTENTS
7
1. SCOPE/GENERAL DESCRIPTION
23
1.1 SCOPE
23
1.2 GENERAL DESCRIPTION
23
1.2.1 SPECIFICATION ORGANIZATION
23
2. OUTLINE OF SPECIFICATIONS
24
2.1 GENERAL DESCRIPTION
24
2.2 DIMENSION
25
2.3 WEIGHT
25
2.4 PRINTING METHOD
25
2.5 HEAD SPECIFICATION
25
2.6 PRINT SPEED
25
2.7 PRINT MODE
25
2.8 FONT TYPE
26
2.8.1 BIT MAP FONT
26
2.8.2 OUTLINE FONT
27
2.9 TYPE OF BARCODE/TWO-DIMENSIONAL CODE
27
2.9.1 BARCODE
27
2.9.2 TWO-DIMENSIONAL CODE
27
2.10 FORMAT STORAGE
27
2.11 GRAPHIC STORAGE
27
2.12 WRITABLE CHARACTER STORAGE
28
2.13 INTERFACE
28
2.14 POWER SOURCE
28
2.15 SWITCH
28
2.16 SENSOR
28
2.17 LED
28
2.18 LCD
29
2.19 SPEAKER
29
2.20 ISSUE MODE
29
2.21 PAPER
29
2.22 CUT
30
2.23 BROKEN HEAD DOTS CHECK FUNCTION
30
2.24 STATUS TRANSMISSION
30
2.25 AUTO LABEL POSITIONING FUNCTION
30
2.26 STATUS PRINTING
30
2.27 CONTINUOUS PRINTING FUNCTION
30
2.28 STRIP ISSUE
31
3. INTERFACE
32
3.1 GENERAL DESCRIPTION
32
3.2 IrDA INTERFACE (TEC Protocol)
33
3.2.1 SPECIFICATIONS FOR PHYSICAL LAYER AND TRANSMISSION CONTROL METHOD
33
3.2.2 INPUT/OUTPUT SIGNAL
34
3.2.3 TRANSMISSION CONTROL
34
3.2.4 HOW TO SEND THE DATA PRINT COMMAND WHICH CANNOT BE INCLUDED IN ONE PACKET IN THE LABEL MODE
42
3.2.5 CONNECTION SEQUENCE EXAMPLE (LABEL MODE)
43
3.2.6 CONNECTION SEQUENCE EXAMPLE (TPCL, RECEIPT OR ESC/POS MODE)
63
3.2.7 PRINTER STATE TRANSITION (LABEL MODE)
69
3.2.8 PRINTER STATE TRANSITION (TPCL, RECEIPT OR ESC/POS MODE)
70
3.2.9 HANDLING OF RECEIVED DATA WHEN THE PRINTER GOES INTO POWER SAVE MODE
71
3.3 IrDA (IrCOMM) INTERFACE
72
3.3.1 HANDLING OF RECEIVED DATA WHEN THE PRINTER GOES INTO POWER SAVE MODE
72
3.4 IrDA (IrOBEX) INTERFACE
73
3.4.1 HANDLING OF RECEIVED DATA WHEN THE PRINTER GOES INTO POWER SAVE MODE
73
3.5 RS-232C INTERFACE
74
3.5.1 TRANSMISSION CONTROL (XON/XOFF PROTOCOL)
74
3.5.2 NOTES WHEN SENDING A COMMAND
75
3.5.3 HANDLING OF RECEIVED DATA WHEN THE PRINTER GOES INTO POWER SAVE MODE
82
3.6 USB INTERFACE
83
3.6.1 HANDLING OF RECEIVED DATA WHEN THE PRINTER GOES INTO POWER SAVE MODE
84
3.7 BLUETOOTH INTERFACE
85
3.7.1 OUTLINED SPECIFICATIONS
85
3.7.2 BLUETOOTH DEVICE ADDRESS (BD ADDRESS)
86
3.7.3 STANDARD COMMUNICATION SEQUENCE OF BLUETOOTH INTERFACE
87
3.7.4 HANDLING OF RECEIVED DATA WHEN THE PRINTER GOES INTO POWER SAVE MODE
105
3.7.5 COMBINATION OF BLUETOOTH MODEL AND APPLICABLE FIRMWARE VERSION
105
3.8 WIRELESS LAN INTERFACE
106
3.8.1 OUTLINED SPECIFICATIONS
106
3.8.2 MAC ADDRESS
107
3.8.3 CONNECTION SEQUENCE
107
3.8.4 HANDLING OF RECEIVED DATA WHEN THE PRINTER GOES INTO POWER SAVE MODE
110
4. TRANSMISSION SEQUENCE
111
4.1 GENERAL DESCRIPTION
111
4.2 TPCL MODE
112
4.2.1 INITIAL SETTING
112
4.2.2 LABEL ISSUE OPERATION
114
4.2.3 HANDLING OF RECEIVED DATA BY COMMAND
116
4.3 LABEL MODE
136
4.3.1 INITIAL SETTING
136
4.3.2 LABEL ISSUE OPERATION
138
4.3.3 HANDLING OF RECEIVED DATA BY COMMAND
139
4.4 RECEIPT MODE
153
4.4.1 INITIAL SETTING
153
4.4.2 RECEIPT ISSUE OPERATION
154
4.4.3 HANDLING OF RECEIVED DATA BY COMMAND
157
4.5 ESC/POS MODE
162
4.5.1 INITIAL SETTING
162
4.5.2 RECEIPT ISSUE OPERATION
163
4.5.3 HANDLING OF RECEIVED DATA BY COMMAND
166
5. TPCL MODE (INTERFACE COMMANDS)
171
5.1 GENERAL DESCRIPTION
171
5.2 OUTLINE OF COMMANDS
174
5.2.1 FORMAT OF INTERFACE COMMAND
174
5.2.2 HOW TO USE REFERENCE
174
5.2.3 PRECAUTIONS
174
5.3 COMMANDS RELATED TO SETTING
175
5.3.1 LABEL SIZE SET COMMAND
175
5.3.2 PRINTER ID SET COMMAND
181
5.3.3 MODE SELECT COMMAND
182
5.4 COMMANDS RELATED TO FINE ADJUSTMENT
184
5.4.1 PRINT START POSITION FINE ADJUST COMMAND
184
5.4.2 PRINT DENSITY FINE ADJUST COMMAND
189
5.4.3 STRIP SENSOR ADJUST COMMAND
192
5.5 COMMANDS RELATED TO CLEAR
193
5.5.1 IMAGE BUFFER CLEAR COMMAND
193
5.5.2 CLEAR AREA COMMAND
194
5.6 COMMANDS RELATED TO DRAWING FORMAT
196
5.6.1 LINE FORMAT COMMAND
196
5.6.2 BIT MAP FONT FORMAT COMMAND
203
5.6.3 OUTLINE FONT FORMAT COMMAND
220
5.6.4 BARCODE FORMAT COMMAND
238
5.6.5 BARCODE FORMAT COMMAND
253
5.6.6 BARCODE FORMAT COMMAND
263
5.6.7 TWO-DIMENSIONAL CODE FORMAT COMMAND (Data Matrix)
273
5.6.8 TWO-DIMENSIONAL CODE FORMAT COMMAND (PDF417)
283
5.6.9 TWO-DIMENSIONAL CODE FORMAT COMMAND (MicroPDF417)
290
5.6.10 TWO-DIMENSIONAL CODE FORMAT COMMAND (QR Code)
298
5.6.11 TWO-DIMENSIONAL CODE FORMAT COMMAND (MaxiCode)
306
5.7 COMMANDS RELATED TO PRINT DATA
312
5.7.1 BIT MAP FONT DATA COMMAND
312
5.7.2 OUTLINE FONT DATA COMMAND
317
5.7.3 BARCODE/TWO-DIMENSIONAL CODE DATA COMMAND (Any codes other than MaxiCode)
320
5.7.4 TWO-DIMENSIONAL CODE DATA COMMAND (MaxiCode)
331
5.8 COMMANDS RELATED TO ISSUE AND FEED
333
5.8.1 ISSUE COMMAND
333
5.8.2 FEED COMMAND
337
5.8.3 STORAGE AREA ALLOCATE COMMAND
339
5.9 COMMANDS RELATED TO FORMAT
341
5.9.1 FLASH MEMORY FORMAT COMMAND
341
5.10 COMMANDS RELATED TO WRITABLE CHARACTERS
342
5.10.1 2-BYTE WRITABLE CHARACTER CODE RANGE COMMAND
342
5.10.2 BIT MAP WRITABLE CHARACTER COMMAND
344
5.11 COMMANDS RELATED TO GRAPHICS
352
5.11.1 GRAPHIC COMMAND
352
5.12 COMMANDS RELATED TO PC COMMAND SAVING
359
5.12.1 SAVE START COMMAND
359
5.12.2 SAVE TERMINATE COMMAND
361
5.12.3 SAVED DATA READ COMMAND
362
5.13 COMMANDS RELATED TO CHECK
363
5.13.1 HEAD BROKEN DOTS CHECK COMMAND
363
5.13.2 MESSAGE DISPLAY COMMAND
364
5.14 COMMANDS RELATED TO CONTROL
366
5.14.1 RESET COMMAND
366
5.14.2 BATCH RESET COMMAND
367
5.15 COMMANDS RELATED TO STATUS
368
5.15.1 STATUS REQUEST COMMAND
368
5.15.2 RECEIVE BUFFER FREE SPACE STATUS REQUEST COMMAND
371
5.15.3 MODE INFORMATION ACQUIRE COMMAND
374
5.15.4 VERSION INFORMATION ACQUIRE COMMAND
377
5.15.5 PRINTER SERIAL NUMBER ACQUIRE COMMAND
379
5.16 COMMANDS RELATED TO BLUETOOTH AND WIRELESS LAN
380
5.16.1 DEVICE ADDRESS ACQUIRE COMMAND
380
5.16.2 BLUETOOTH RELATED PARAMETER ACQUIRE COMMAND
381
6. LABEL MODE (INTERFACE COMMANDS)
382
6.1 GENERAL DESCRIPTION
382
6.2 OUTLINE OF COMMANDS
384
6.2.1 FORMAT OF INTERFACE COMMAND
384
6.2.2 HOW TO USE REFERENCE
384
6.2.3 PRECAUTIONS
384
6.3 COMMANDS RELATED TO SETTING
385
6.3.1 LABEL SIZE SET COMMAND
385
6.3.2 PRINTER ID SET COMMAND
388
6.3.3 MODE SELECT COMMAND
389
6.4 COMMANDS RELATED TO FINE ADJUSTMENT
392
6.4.1 PRINT START POSITION FINE ADJUST COMMAND
392
6.4.2 PRINT DENSITY FINE ADJUST COMMAND
395
6.4.3 STRIP SENSOR THRESHOLD VALUE SET COMMAND
397
6.5 COMMANDS RELATED TO DRAWING FORMAT
398
6.5.1 LINE FORMAT COMMAND
398
6.5.2 BIT MAP FONT FIELD COMMAND
400
6.5.3 OUTLINE FONT FIELD COMMAND
406
6.5.4 BARCODE FORMAT COMMAND (MSI, ITF, CODE39, NW7)
415
6.5.5 BARCODE FORMAT COMMAND (JAN8/EAN8, JAN13/EAN13)
417
6.5.6 BARCODE FORMAT COMMAND (EAN128, UCC/EAN128)
418
6.5.7 BARCODE FORMAT COMMAND (CODE128)
419
6.5.8 BARCODE FORMAT COMMAND (CUSTOMER BARCODE)
421
6.5.9 two-dimensional CODE FORMAT COMMAND (PDF417)
422
6.5.10 two-dimensional CODE FORMAT COMMAND (QR CODE)
425
6.5.11 TWO-DIMENSIONAL CODE FORMAT COMMAND (DATA MATRIX)
427
6.5.12 TWO-DIMENSIONAL CODE FORMAT COMMAND (MIRCOPDF417)
429
6.5.13 TWO-DIMENSIONAL CODE FORMAT COMMAND (MAXICODE)
430
6.6 COMMANDS RELATED TO ISSUE AND FEED
436
6.6.1 DATA PRINT COMMAND
436
6.7 COMMANDS RELATED TO FORMAT
443
6.7.1 FLASH MEMORY STORAGE AREA FORMAT COMMAND
443
6.7.2 STORAGE AREA ALLOCATE COMMAND
444
6.8 COMMANDS RELATED TO WRITABLE CHARACTERS
446
6.8.1 WRITABLE CHARACTER DATA STORE COMMAND
446
6.9 COMMANDS RELATED TO GRAPHICS
448
6.9.1 GRAPHIC DATA STORE COMMAND
448
6.9.2 GRAPHIC FIELD COMMAND
450
6.10 COMMANDS RELATED TO PC COMMAND SAVING
451
6.10.1 FORM STORE START COMMAND
451
6.10.2 FORM STORE TERMINATE COMMAND
452
6.11 COMMANDS RELATED TO CHECK
453
6.11.1 MESSAGE DISPLAY COMMAND
453
6.12 COMMANDS RELATED TO CONTROL
454
6.12.1 INITIALIZE COMMAND
454
6.12.2 BATCH RESET COMMAND
455
6.13 COMMANDS RELATED TO STATUS
456
6.13.1 STATUS REQUEST COMMAND
456
6.13.2 RECEIVE BUFFER FREE SPACE STATUS REQUEST COMMAND
459
6.13.3 MODE INFORMATION ACQUIRE COMMAND
462
6.13.4 VERSION INFORMATION ACQUIRE COMMAND
465
6.13.5 PRINTER SERIAL NUMBER ACQUIRE COMMAND
467
6.14 COMMANDS RELATED TO BLUETOOTH AND WIRELESS LAN
468
6.14.1 DEVICE ADDRESS ACQUIRE COMMAND
468
6.14.2 BLUETOOTH RELATED PARAMETER ACQUIRE COMMAND
469
7. RECEIPT MODE (INTERFACE COMMANDS)
470
7.1 GENERAL DESCRIPTION
470
7.2 OUTLINE OF COMMANDS
471
7.2.1 FORMAT OF INTERFACE COMMAND
471
7.2.2 HOW TO USE REFERENCE
471
7.2.3 PRECAUTIONS
472
7.3 COMMANDS RELATED TO SETTING
473
7.3.1 MODE SELECT COMMAND
473
7.3.2 PRINTER ID SET COMMAND
476
7.4 COMMANDS RELATED TO FINE ADJUSTMENT
477
7.4.1 LINE FEED LENGTH SET COMMAND
477
7.4.2 PRINT POSITION ALIGN COMMAND
478
7.4.3 PRINT DENSITY FINE ADJUST COMMAND
479
7.5 COMMANDS RELATED TO DRAWING FORMAT
481
7.5.1 LINE FORMAT COMMAND
481
7.5.2 FONT TYPE COMMAND
483
7.5.3 OUTLINE FONT FORMAT COMMAND
484
7.5.4 BARCODE/TWO-DIMENSIONAL CODE PRINT COMMAND
485
7.5.5 CHARACTER MAGNIFICATION COMMAND
487
7.5.6 BARCODE HORIZONTAL SIZE COMMAND
488
7.5.7 BARCODE HEIGHT COMMAND
490
7.5.8 NUMERALS UNDER BARS COMMAND
491
7.5.9 SECURITY LEVEL COMMAND
492
7.5.10 NO. OF COLUMNS (STRINGS) COMMAND
493
7.5.11 PRINT WIDTH COMMAND
494
7.5.12 HORIZONTAL PRINT POSITION COMMAND
495
7.5.13 HORIZONTAL OFFSET POSITION COMMAND
497
7.5.14 CHARACTER ROTATE COMMAND
499
7.5.15 ERROR CORRECTION LEVEL SET COMMAND
500
7.5.16 QR CODE MODEL SET COMMAND
501
7.6 COMMANDS RELATED TO ISSUE AND FEED
502
7.6.1 PRINT LINE FEED COMMAND
502
7.6.2 BACK FEED OMISSION COMMAND
503
7.6.3 PAGE MODE SELECT COMMAND
504
7.6.4 PAGE MODE PRINT COMMAND
505
7.6.5 PAGE MODE CANCEL COMMAND
506
7.7 COMMANDS RELATED TO FORMAT
507
7.7.1 FLASH MEMORY FORMAT COMMAND
507
7.8 COMMANDS RELATED TO GRAPHICS
508
7.8.1 GRAPHIC DATA STORE COMMAND
508
7.8.2 GRAPHIC PRINT COMMAND
510
7.9 COMMANDS RELATED TO CONTROL
511
7.9.1 INITIALIZE COMMAND
511
7.10 COMMANDS RELATED TO STATUS
512
7.10.1 STATUS REQUEST COMMAND
512
7.10.2 RECEIVE BUFFER FREE SPACE STATUS REQUEST COMMAND
514
7.10.3 MODE INFORMATION ACQUIRE COMMAND
517
7.10.4 VERSION INFORMATION ACQUIRE COMMAND
519
7.10.5 PRINTER SERIAL NUMBER ACQUIRE COMMAND
521
7.11 COMMANDS RELATED TO BLUETOOTH AND WIRELESS LAN
522
7.11.1 DEVICE ADDRESS ACQUIRE COMMAND
522
7.11.2 BLUETOOTH RELATED PARAMETER ACQUIRE COMMAND
523
7.12 COMMANDS RELATED TO MACRO SETTING
524
7.12.1 MACRO DEFINITION COMMAND
524
7.12.2 MACRO EXECUTE COMMAND
525
7.13 EXAMPLES
526
7.13.1 EXAMPLES OF USING COMMANDS
526
8. ESC/POS MODE (INTERFACE COMMAND)
528
8.1 GENERAL DESCRIPTION
528
8.2 OUTLINE OF COMMANDS
529
8.2.1 FORMAT OF INTERFACE COMMAND
529
8.2.2 HOW TO USE REFERENCE
529
8.2.3 PRECAUTIONS
530
8.3 FONT SPECIFICATIONS
530
8.4 EXTERNAL (CUSTOM) CHARACTERS SPECIFICATIONS
530
8.5 INPUT DATA BUFFER
530
8.6 VALUE SPECIFIED BY EACH COMMAND
531
8.7 EXPANSION OF PRINT DATA IN PRINT AREA
532
8.8 EXAMPLE OF RECEIPT PRINTER PRINT LAYOUT (B-EP2DL)
533
8.9 EXCEPTION HANDLING
534
8.9.1 UNDEFINED CODE
534
8.9.2 UNDEFINED COMMAND
534
8.9.3 SETTING OUT OF DEFINED RANGE
534
8.10 ESC/POS COMMANDS
535
8.10.1 HORIZONTAL TAB COMMAND
535
8.10.2 LINE FEED COMMAND
536
8.10.3 PAGE MODE PRINT COMMAND
537
8.10.4 PAGE MODE CANCEL COMMAND
538
8.10.5 PAGE MODE COLLECTIVE PRINT COMMAND
539
8.10.6 SPACING SET COMMAND
540
8.10.7 PRINT MODE ALL SET COMMAND
541
8.10.8 DOWNLOADED CHARACTER (WRITABLE CHARACTER) SET COMMAND
543
8.10.9 DOWNLOADED CHARACTER (WRITABLE CHARACTER) DEFINE COMMAND
544
8.10.10 BIT IMAGE MODE SELECT COMMAND
547
8.10.11 UNDERLINING SET COMMAND
550
8.10.12 DOWNLOADED CHARACTER ERASE COMMAND
551
8.10.13 30-DOT LINE FEED LENGTH SET COMMAND
552
8.10.14 MINIMUM DOTS FOR LINE FEED LENGTH SET COMMAND
553
8.10.15 PRINTER SELECT/DESELECT COMMAND
554
8.10.16 INITIALIZE COMMAND
555
8.10.17 HORIZONTAL TAB POSITIONS SET COMMAND
557
8.10.18 BOLD PRINTING SET COMMAND
559
8.10.19 DOUBLE PRINTING SET COMMAND
560
8.10.20 FEED LENGTH SET COMMAND
561
8.10.21 SWITCHING TO PAGE MODE COMMAND
562
8.10.22 INTERNATIONAL CHARACTER SELECT
563
8.10.23 SWITCHING TO STANDARD MODE COMMAND
565
8.10.24 PAGE MODE PRINT DIRECTION SET COMMAND
566
8.10.25 CHARACTER ROTATION SET COMMAND
567
8.10.26 PAGE MODE PRINT AREA SET COMMAND
568
8.10.27 JUSTIFICATION COMMAND
570
8.10.28 PANEL KEY (FEED KEY) SET COMMAND
571
8.10.29 PAPER FEED LENGTH SET COMMAND
572
8.10.30 CODE PAGE NO. SELECT COMMAND
573
8.10.31 INVERTED PRINTING SET COMMAND
574
8.10.32 ABSOLUTE POSITION SET COMMAND
575
8.10.33 RELATIVE POSITION SET COMMAND
576
8.10.34 CHINESE CHARACTER PRINT MODE ALL SET COMMAND
577
8.10.35 CHINESE CHARACTER MODE SET COMMAND
578
8.10.36 CHINESE CHARACTER UNDERLINING SET COMMAND
579
8.10.37 CHINESE CHARACTER MODE CANCEL COMMAND
580
8.10.38 WRITABLE CHARACTER OF CHINESE CHARACTER DEFINE COMMAND
581
8.10.39 CHINESE CHARACTER CODE SYSTEM SET COMMAND
583
8.10.40 CHINESE CHARACTER SPACING SET COMMAND
585
8.10.41 CHINESE CHARACTER MAGNIFICATION SET COMMAND
587
8.10.42 PAGE MODE ABSOLUTE POSITION SET COMMAND
588
8.10.43 REVERSE CHARACTER SET COMMAND
589
8.10.44 ID TRANSMISSION COMMAND
590
8.10.45 PAGE MODE RELATIVE POSITION IN VERTICAL DIRECTION SET COMMAND
591
8.10.47 BARCODE PRINT COMMAND
592
8.10.48 APPENDIX: BARCODE
596
8.10.49 BARCODE HORIZONTAL SIZE COMMAND
599
8.10.50 BARCODE HEIGHT COMMAND
601
8.10.51 NUMERALS UNDER BARS COMMAND
602
8.10.52 PRINT AREA WIDTH SET COMMAND
603
8.10.53 DOWNLOADED BIT IMAGE DEFINE COMMAND
604
8.10.54 DOWNLOADED BIT IMAGE PRINT MODE SET COMMAND
606
8.10.55 MACRO DEFINITION START/END COMMAND
607
8.10.56 MACRO EXECUTE COMMAND
608
8.10.58 LEFT MARGIN SET COMMAND
609
8.10.59 CHARACTER SIZE SET COMMAND
610
8.11 TEC ORIGINAL COMMANDS
611
8.11.1 MODE SELECT COMMAND
611
8.11.2 RESET COMMAND
614
8.11.3 STATUS REQUEST COMMAND
615
8.11.4 RECEIVE BUFFER FREE SPACE STATUS REQUEST COMMAND
617
8.11.5 MODE INFORMATION ACQUIRE COMMAND
620
8.11.6 PRINTER SERIAL NUMBER ACQUIRE Command
623
8.11.7 DEVICE ADDRESS ACQUIRE COMMAND
624
8.11.8 BLUETOOTH RELATED PARAMETER ACQUIRE COMMAND
625
9. ERROR PROCESSING
627
9.1 GENERAL DESCRIPTION
627
9.2 COMMUNICATION ERRORS
628
9.2.1 COMMAND SYNTAX ERROR
628
9.2.2 HARDWARE ERROR
628
9.2.3 LAN DRIVER ERROR
628
9.3 ERRORS IN ISSUING OR FEEDING
629
9.3.1 PAPER JAM / LABEL END / NORMAL END + LABEL END
629
9.3.2 BROKEN HEAD DOTS ERROR
631
9.3.3 THERMAL HEAD EXCESSIVE TEMPERATURE
631
9.3.4 COVER OPEN ERROR
631
9.4 BATTERY ERROR
632
9.4.1 LOW BATTERY
632
9.4.2 ABNORMAL HIGH VOLTAGE
632
9.4.3 ABNORMAL BATTERY TEMPERATURE
632
9.5 CHARGING ERROR
632
9.6 BLUETOOTH SETTING ERROR
632
9.7 ERRORS IN WRITABLE CHARACTER AND PC COMMAND SAVE MODES
632
9.7.1 WRITE ERROR
632
9.7.2 FORMAT ERROR
632
9.7.3 MEMORY FULL
632
9.8 SYSTEM ERRORS
633
9.8.1 ADDRESS ERROR
633
9.8.2 GENERAL INVALID COMMAND EXCEPTION
633
9.8.3 SLOT INVALID EXCEPTION
633
9.8.4 PCB IDENTIFICATION ERROR
633
9.8.5 THERMAL HEAD IDENTIFICATION ERROR
633
9.9 OPERATIONS WHEN AN ERROR OCCURS
634
9.10 OPERATIONS AFTER AN ERROR IS CLEARED
634
9.10.1 LABEL MODE
634
9.10.2 RECEIPT MODE
634
9.10.3 RECEIPT1 MODE OR ESC/POS MODE
634
9.10.4 TPCL MODE
634
9.11 STATUS VALUES
635
10. SYSTEM MODE
640
10.1 GENERAL DESCRIPTION
640
10.2 STARTING THE PRINTER IN SYSTEM MODE
640
10.3 COMMUNICATIONS CONDITIONS
640
10.4 LIMITATIONS IN SYSTEM MODE
640
10.5 OUTLINE OF COMMANDS
641
10.5.1 FORMAT OF INTERFACE COMMAND
641
10.5.2 HOW TO USE REFERENCE
641
10.5.3 PRECAUTIONS
641
10.6 COMMANDS RELATED TO SETTING
642
10.6.1 ID SET COMMAND
642
10.6.2 MODE SELECT COMMAND
643
10.7 COMMANDS RELATED TO FINE ADJUSTMENT
646
10.7.1 PRINT START POSITION FINE ADJUST COMMAND
646
10.7.2 PRINT DENSITY FINE ADJUST COMMAND
650
10.7.3 STRIP SENSOR THRESHOLD VALUE SET COMMAND
652
10.8 COMMANDS RELATED TO CONTROL
653
10.8.1 INITIALIZE COMMAND
653
10.9 COMMANDS RELATED TO STATUS
654
10.9.1 STATUS REQUEST COMMAND
654
10.9.2 MODE INFORMATION ACQUIRE COMMAND
660
10.9.3 PRINTER SERIAL NUMBER ACQUIRE COMMAND
662
10.10 COMMANDS RELATED TO BLUETOOTH AND WIRELESS LAN
663
10.10.1 DEVICE ADDRESS ACQUIRE COMMAND
663
10.10.2 BLUETOOTH DEVICE NICKNAME SETTING
664
10.10.3 INQUIRY RESPONSE TIME SETTING COMMAND
665
10.10.4 INTERVAL/WINDOW SETTING AT THE INQUIRY/PAGE
666
10.10.5 BONDING SETTING COMMAND
667
10.10.6 BONDING TABLE DELETION COMMAND
669
10.10.7 SECURITY SETTING COMMAND
670
10.10.8 BLUETOOTH RELATED PARAMETER ACQUIRE COMMAND
672
10.11 SETUP MODE
674
10.11.1 GENERAL DESCRIPTION
674
10.11.2 HOW TO ENTER INTO SETUP MODE
674
10.11.3 AUTO POWER-OFF FUNCTION DURING SETTING
674
10.11.4 HOW TO CHECK EACH SETUP MODE
674
10.11.5 OTHER
674
11. OTHER FUNCTIONS
675
11.1 GENERAL DESCRIPTION
675
11.2 REPRINT FUNCTION
676
11.2.1 LABEL MODE
676
11.2.2 RECEIPT OR ESC/POS MODE
676
11.2.3 TPCL MODE
676
11.2.4 TPCL1 MODE
676
11.3 POWER SAVE MODE
676
11.4 AUTOMATIC LABEL PRINT POSITIONING
677
11.4.1 LABEL MODE, TPCL MODE
677
11.4.2 RECEIPT MODE
677
11.5 CONTINUOUS PRINTING FUNCTION
677
11.5.1 LABEL MODE, RECEIPT MODE (Mode = 1)
677
11.5.2 RECEIPT1 MODE (Mode = 2), TPCL MODE (Mode = A), TPCL1 MODE (Mode = B), ESC/POS
677
11.6 AUTOMATIC LABEL PRINT POSITIONING AT POWER ON TIME
677
11.6.1 DESTINED FOR JAPAN
677
11.6.2 DESTINED OVERSEAS
677
11.7 BD ADDRESS PRINTING FUNCTION
677
11.8 WIRELESS LAN PARAMETER SETTINGS PRINTING FUNCTION
678
11.9 STRIP ISSUE MODE
678
11.11 STATUS
679
11.11.1 FUNCTIONS
679
11.11.2 STATUS FORMAT
681
11.11.3 DETAIL STATUS
684
11.12 LCD MESSAGES AND LED INDICATIONS
690
11.13 LIST OF CHARGING ERROR NO. AND DETAILS
692
11.14 LCD MESSAGES IN DIFFERENT LANGUAGES
693
11.15 RECOVERY OF BD ADDRESS
696
11.15.1 RECOVERY OF BONDING TABLE
697
12. CHARACTER CODE TABLE
699
12.1 GENERAL DESCRIPTION
699
12.2 CHARACTER CODE
699
12.2.1 UTF-8 CHARACTER CODE
699
12.3 TIMES ROMAN, HELVETICA, LETTER GOTHIC, PRESTIGE ELITE, COURIER,
700
12.4 PRESENTATION
711
12.5 OCR-A
715
12.6 OCR-B
719
12.7 STANDARD CHARACTER (in Japan)/KANJI (16 x 16) (in Japan)/
723
12.8 STANDARD CHARACTER (outside Japan)
725
12.9 CHINESE CHARACTER (24 x 24) (outside Japan)
727
12.10 KOREAN CHARACTER (24 x 24) (outside Japan)
729
12.11 BOLD CHARACTER
731
12.12 PRICE CHARACTER 1/PRICE CHARACTER 2
732
12.13 TEC OUTLINE FONT 1
733
12.14 PRICE FONT 1, 2, 3
743
16. BARCODE/TWO-DIMENSIONAL CODE TABLE
744
16.1 GENERAL DESCRIPTION
744
16.2 JAN8/EAN8, JAN13/EAN13, UPC-E, UPC-A, UCC/EAN128, EAN128, Interleaved 2 of 5 (ITF), MSI, Industrial 2 of 5, RSS-14, RSS-14 Stacked, RSS-14 Stacked Omni-directional, RSS Limited, EAN13 + 2 digits, EAN13 + 5 digits, UPC-E + 2 digits, UPC-E + 5 digits, EAN8 + 2 digits, EAN8 + 5 digits, UPC-A + 2 digits, UPC-A + 5 digits
745
16.3 CUSTOMER BARCODE
746
16.4 POSTNET
747
16.5 RM4SCC
747
16.6 KIX CODE
748
16.7 CODE39 (Standard)
749
16.8 CODE39 (Full ASCII)
750
16.9 NW-7
751
16.10 CODE93
752
16.11 CODE128
753
16.11.1 TRANSFER CODE
753
16.11.2 HOW TO TRANSMIT THE CONTROL CODE DATA
753
16.11.3 HOW TO TRANSMIT THE SPECIAL CODES
753
16.11.4 DESIGNATION OF START CODE
753
16.11.5 VALUE CODE TABLE
754
16.11.6 RSS EXPANDED, RSS EXPANDED STACKED
755
16.12 DATA MATRIX
756
16.12.1 FORMAT ID
756
16.12.2 TRANSFER CODE
756
16.12.3 HOW TO TRANSMIT THE CONTROL CODE DATA
756
16.12.4 HOW TO TRANSMIT THE SPECIAL CODES
756
16.12.5 HOW TO TRANSMIT THE KANJI CODES
756
16.13 PDF417, MicroPDF417
757
16.13.1 MODE/CODE
757
16.13.2 TRANSFER CODE
758
16.13.3 HOW TO TRANSMIT THE CONTROL CODE DATA
758
16.13.4 HOW TO TRANSMIT THE SPECIAL CODES
758
16.13.5 HOW TO TRANSMIT THE KANJI CODES
758
16.14 QR CODE
759
16.14.1 MODE SELECTION
759
16.14.2 TRANSFER CODE
760
16.14.3 HOW TO TRANSMIT THE CONTROL CODE DATA
761
16.14.4 HOW TO TRANSMIT THE SPECIAL CODES
761
16.14.5 HOW TO TRANSMIT THE KANJI CODES
761
16.15 MAXICODE
762
16.15.1 When the MaxiCode specification is set to “TYPE1: Compatible with the current version” in the system mode:
763
16.15.2 When the MaxiCode specification is set to “TYPE2: Special specification” in the system mode:
764
16.16. DRAWING OF BARCODE DATA
765
16.17. AUTOMATIC ADDITION OF START/STOP CODES
787
Other manuals for Toshiba B-EP4DL-GH32-QM-R
Owner's Manual
21 pages
5
Based on 1 rating
Ask a question
Give review
Questions and Answers:
Need help?
Do you have a question about the Toshiba B-EP4DL-GH32-QM-R and is the answer not in the manual?
Ask a question
Toshiba B-EP4DL-GH32-QM-R Specifications
General
Brand
Toshiba
Model
B-EP4DL-GH32-QM-R
Category
Printer
Language
English
Related product manuals
Toshiba B-EP4DL-GH20-QM-R
21 pages
Toshiba B-EP2DL
28 pages
Toshiba B-EP Series
228 pages
Toshiba B-EP2DL Series
36 pages
Toshiba B-EP2DL-GH40-QM-R
105 pages
Toshiba B-EV4 Series
280 pages
Toshiba B-EX4 SERIES
294 pages
Toshiba B-EX4 T1 Series
57 pages
Toshiba B-SA4TM SERIES
132 pages
Toshiba B-SA4TP SERIES
132 pages
Toshiba B-FV4T-GS12-QM-R
63 pages
Toshiba TEC B B-SX5T SERIES
56 pages
To Next PageTo Next PageTo Previous PageTo Previous Page
Loading...
Need help?
General
