CHAPTER 5 TPCL-LE MODE (INTERFACE COMMANDS)
B-EP Series
5-188
[TOPIX compression mode]
[ESC] SG; 0100, 0240, 0019, 0300, 3, 00 5C 80 80 40 30
Length L1 L2 L3 Data (1st line)
80 80 40 08 80 80 40 04 80 80 40 02 80 80 40 09
(2nd line) (3rd line) (4th line) (5th line)
80 80 60 04 80 80 80 60 02 40 80 80 40 01 80 80 20 20
(6th line) (7th line) (8th line) (9th line)
80 80 20 80 80 80 20 80 80 80 20 20 80 80 40 01
(10th line) (11th line) (12th line) (13th line)
80 80 60 02 40 80 80 A0 0F 80 80 80 C0 30 C3 80 80 80 40
(14th line) (15th line) (16th line) (17th line)
80 80 80 80 80 80 40 10 00 80 80 C0 80 20 80 80 C0 40 C0 [LF] [NUL]
(18th line) (19th line)(20th line) (21st line) (22nd line)
Origin
(0, 0)
Graphic width 19 dots
Graphic
height
22 dots
24.0 mm
10.0 mm
To Next Page
