CHAPTER 5 TPCL-LE MODE (INTERFACE COMMANDS)
B-EP Series
5-205
TPCL1 mode (Mode = B)
Batch issue mode
[IrDA: TEC Protocol]
STX Mode information (16 bytes) CRC CRC
T P C L 1 SP SP SP SP SP SP SP SP SP SP SP
02H 54H 50H 43H 4CH 2DH 4CH 45H 20H 20H 20H 20H 20H 20H 20H 20H 20H xxH xxH
[IrDA: IrCOMM, IrDA: IrOBEX, USB, RS-232C, Bluetooth, Wireless LAN]
SOH STX Mode information (16 bytes) ETX EOT CR LF
T P C L 1 SP SP SP SP SP SP SP SP SP SP SP
01H 02H 54H 50H 43H 4CH 31H 20H 20H 20H 20H 20H 20H 20H 20H 20H 20H 20H 03H 04H 0DH 0AH
Strip issue mode
[IrDA: TEC Protocol]
STX Mode information (16 bytes) CRC CRC
T P C L 1 ( S ) SPSPSPSPSPSPSPSP
02H 54H 50H 43H 4CH 31H 28H 53H 29H 20H 20H 20H 20H 20H 20H 20H 20H xxH xxH
[IrDA: IrCOMM, IrDA: IrOBEX, USB, RS-232C, Bluetooth, Wireless LAN]
SOH STX Mode information (16 bytes) ETX EOT CR LF
T P C L 1 ( S ) SP SP SP SP SP SP SP SP
01H 02H 54H 50H 43H 4CH 31H 28H 53H 29H 20H 20H 20H 20H 20H 20H 20H 20H 03H 04H 0DH 0AH
The above is an example where the message is received in the TPCL and TPCL-LE modes as well as
when the compatible mode for the B-SP series is off. In addition, the following messages are returned.
TPCL mode TPCL
TPCL1 mode TPCL1
LABEL mode LABEL
RECEIPT mode RECEIPT
RECEIPT1 mode RECEIPT1
ESC/POS mode ESC/POS
Online reset menu USERSYSTEM
SYSTEM mode for users
PAUSE + POWER keys
USERSYSTEM
SYSTEM mode for administrators
FEED + POWER keys
When the password setting is on
and before it is entered
USERSYSTEM
When the password setting is on
and after it is entered
SYSTEM
When the password setting is off SYSTEM
TPCL (strip issue mode) TPCL(S)
TPCL1 (strip issue mode) TPCL1 (S)
LABEL (strip issue mode) LABEL (S)
* indicates a space.
