CHAPTER 6 LABEL MODE (INTERFACE COMMANDS)
B-EP Series
6-18
e Rectangle
(2) When the start and end point coordinates which make a slant line are specified, a rectangle
is drawn, even if “Line” is selected for the line type.
(3) If the print ratio of one line (the print head width) is higher than defined, printing may
become poor, or the printer may be reset. When a horizontal line is to be drawn, note the
print ratio.
(4) When the coordinates, which make data over the head width, is specified, printing is not
guaranteed.
(X
1
,Y
1
)
(X
2
,Y
2
) (X
1
,Y
1
)
(X
2
,Y
2
)
Line width
Line width
Line
width
Line width
To Next Page
