CHAPTER 6 LABEL MODE (INTERFACE COMMANDS)
B-EP Series
6-23
(5) Rotational angles of a character and character string
(6) Data length, Data code
JIS 8 code .................... The length that one-byte data is counted as one digit
Packed BCD ................. The length before packed
Data code Data Data to be sent Data length
JIS 8 1 2 3 4 5 31H 32H 33H 34H 35H 5
Packed BCD 1 2 3 4 5 12H 34H 50H 5
* When the same data is sent, the data length to be set is the same value in both
data codes, JIS 8 and Packed BCD.
(7) Print position
• Left (Default)
• Center
• Right
Origin
Origin
Origin
270°
Origin
0° 90° 180°
Sample
