CHAPTER 6 LABEL MODE (INTERFACE COMMANDS)
B-EP Series
6-43
Examples of using commands in PDF417
~ Form storage
[ESC] ID; 01H23H [LF] [NUL] : ID setting
[ESC] XO; 01, 1 [LF] [NUL] : Declaration of the start of form storage
[ESC] D0360, 0480, 0330 [LF] [NUL] : Label size setting
[ESC] XB00; 0000, 0000, P, 00, 02, 06, 0, 0010, 00, 1, 0 [LF] [NUL] : Format of two-dimensional code No. 00
[ESC] XP [LF] [NUL] : Declaration of the termination of form storage
~ Drawing and issue (for IrDA: TEC Protocol)
Command packet in the case that 300-byte issue data is designated in PDF417
(Since the data length is 250 bytes or more, the data is sent by using the command packet in the
RECEIPT mode.)
[Example]
[STX] 01
H 23H deH Y 80H X 01H 00H 03H ABCDEFGHIJKLMNOPQRSTUVWXYZ0123456789
No. of labels to be issued: 3
Transmissive sensor designated,
No status response made
Form No.: 1
Flag (Middle block)
Mode (Fixed at “Y”: Indicates the RECEIPT mode.)
Packet length (de
H = 222 bytes)
Printer ID (0123
H)
ABCDEFGHIJKLMNOPQRSTUVWXYZ0123456789ABCDEFGHIJKLMNOPQRSTUVWXYZ0123456789
ABCDEFGHIJKLMNOPQRSTUVWXYZ0123456789ABCDEFGHIJKLMNOPQRSTUVWXYZ0123456789
ABCDEFGHIJKLMNOPQRSTUVWXYZ0123456789
[CRC] [CRC]
[STX] 01H 23H 57H Y 01H ABCDEFGHIJKLMNOPQRSTUVWXYZ0123456789
ABCDEFGHIJKLMNOPQRSTUVWXYZ0123456789
ABCDEFGHIJKL
[CRC] [CRC]
Flag (Middle block)
Packet length (57
H = 87 bytes)
To Next Page
