USTER®
HVI 900
Instruction Manual
Uster Technologies, Inc.
Chapter 6
Version 4.0 (1.99) HVI 900 System Testing - Page 6-21
8 Printing the Test Results
If the Status selection for System Test Results is either Printer or
Printer/External, the printer should be ON and On-line before testing
begins. If the printer is Off-line (the light indicating the printers' status is
not illuminated), the system displays the error message, "Printer not
ready, press any key." The user is given three opportunities to correct
the problem. After the third time the message is displayed without the
problem being resolved, the test results will not be sent to the printer,
and system testing will resume. If the problem is not fixed, the message
will display after each sample has been tested. If you cannot fix the
printer problem, System Testing Results should be set to "None" or
"External Computer" on the STATUS MENU until the problem is resolved.
The figures below are samples of the test results printouts. When using
the HVI Calibration Mode (the first example), length is reported in UHM
(upper-half mean length) and ML (mean length). In ICC Calibration
Mode (the second example), length is reported in columns labeled 2.5
% and 50 %. Because each sample can be tested multiple times for any
given parameter as defined during Status, the test results printed are an
average of the observations for that parameter.
HVI Calibration Mode
Identifier -->testhvi Date: 06/15/95
HVI Calibration Mode
Id
Grade T %Area Cnt UHM ML Un SFI Str El Mic Rd B C-G
45784 42 5 0.78 17 0.94 1.13 83.4 6.5 28.4 5.9 4.4 68.6 9.3 42-
1
45786 42 4 0.66 11 0.90 1.09 82.3 8.1 26.0 5.8 4.2 68.4 9.3 42-
1
45793 42 5 1.02 15 0.91 1.12 81.4 8.8 25.7 6.0 4.9 70.6 9.0 41-
1
45794 42 4 0.65 9 0.93 1.11 84.0 5.8 27.0 5.9 4.8 70.7 8.9 42-
1
45769 43 4 0.68 12 0.91 1.09 83.4 6.8 25.0 5.8 4.8 71.0 9.3 42-
1
