6 Connections
The balance, monitor, keyboard, temperature/relative humidity probe
and bar code reader should be connected before the HVI 900 is turned
ON.
• Balance
Connect the balance to the cable labeled COM1 (located in the
Micronaire cabinet).
• Monitor
Connect the monitor to the connector labeled VGA on the back of
the HVI. Additional information on the monitor is available in the
Appendix.
• Keyboard
The keyboard is attached to the connector labeled KB on the back of
the HVI.
• Temperature/Relative Humidity Probe
The probe cable is attached to a connector on the back of the HVI
computer.
• Bar Code Reader (if this option is purchased)
Connect the bar code reader to the cable labeled COM2 (located in
the Micronaire cabinet).
The HVI 900 system is now ready for use. Allow the system to warm up
for at least four (4) hours before performing calibrations for the first
time. After 4 hours, calibrate according to the instructions in this
manual.
