9 System Testing Diagnostics
The F8 key displays the current action of the instrument in the
information box in the lower right corner. The message is constantly
replaced as the operation of the instrument changes to complete the
measurement process. This information is particularly helpful if there is
a problem with the instrument and the measurement process is halted in
mid-operation. The message displayed indicates the state of the
instrument when the problem occurred. The following information is a
guideline for diagnostic purposes.
Message What It Means
Comb Home — Comb home sensor not functional
— Sequence error*
New Comb — New comb sensor not functional
— Brusher busy
— Sequence error*
Comb Read — Problem in communicating with the motor
controller. First, try resetting the motor. If
this does not work, reset the system.
Length Done — Length timeout has occurred
— Problem in communicating with the motor
controller. First, try resetting the motor. If
this does not work, reset the system.
— Sequence error*
Comb Ready for Ret — Sequence error*
Comb Return — Problem in communicating with the motor
controller. First, try resetting the motor. If
this does not work, reset the system.
— Waiting on motor to complete movement
Return Done — Waiting on motor to complete movement
Length Interrupt — Waiting on length data
Comb Rdy for Brk — Sequence error*
Comb to Break — Waiting on motor to complete movement
Strength Interrupt — Waiting on strength data
— Clamp sensors not functional
