Fig 11-28 Water separator - view 8
8 Remove the lifting tool (003, Figure 11-28) from the top of the water separator (004) and
attach it to the front of the water separator (004).
9 Operate the spur-geared chain block (001) to lift the water separator slightly.
10 Operate the lever chain hoist (005, Figure 11-27) until the water separator (004, Figure
11-28) is at the correct position.
11 Remove the lifting tool (003).
X72DF
AA00-6708-00AAA-720A-A
Maintenance Manual Water separator - install
Winterthur Gas & Diesel Ltd.
- 667 - Issue 002 2020-10
