Pos. Ind. Part No. Quantity Description Remark
133 3 KX 94095 1 Piece Adapter piece 3/8" to 1/2"
nil 1 - Tool general spanners -
nil 2 - 1 Piece Accessory parts -
136 3 94022B−60 1 Piece Socket wrench insert SW60
137 3 94022B−50 1 Piece Socket wrench insert SW50
138 3 94022B−46 1 Piece Socket wrench insert SW46
139 3 94022B−41 1 Piece Socket wrench insert SW41
140 3 94022B−36 1 Piece Socket wrench insert SW36
141 3 94022B−19 1 Piece Socket wrench insert SW19
142 3 94022D−06 1 Piece Socket wrench insert SW6
143 3 94022A−10 1 Piece Socket wrench insert SW10
144 3 94022F 1 Piece Reducer 3/8"
145 3 94022G 1 Piece Reducer 3/4"
146 3 TN 94153 1 Piece Socket wrench insert 1/2"
147 3 94022C−22 1 Piece Crowfoot wrench -
148 3 94022C−24 1 Piece Crowfoot wrench -
149 3 94022C−42 1 Piece Crowfoot wrench -
150 3 TN 94154 1 Piece Socket wrench insert -
151 4 TN 94155 1 Piece Socket wrench insert AF41
152 4 TN 94156 1 Piece Socket wrench insert AF65
153 3 TN 94157 1 Piece Socket wrench insert AF55
154 3 TN 94158 1 Piece Special hexagon socket screw key SW10
155 3 TN 94159 1 Piece Crowfoot wrench SW30
156 2 KX 94111 1 Piece Socket wrench set ½” (AF10-24 26-28 30 32 33 34 36)
157 2 KX 94112 1 Piece Hex head drivers ½” (AF5-10 12 14 17)
158 2 94022H 1 Piece Dismantling and assembling tool AF12, X = 300
159 2 94023A 1 Piece Assembly tool AF13, X = 225
nil 1 - Tool general pres. measurement -
161 2 94051 1 Piece Tool for pressure measurement Contains: pressure generator 700 bar.
HP hose; G 1/4" male connector; 1/4"
NPT male connector
162 2 94050 1 Piece Tool for pressure measurement -
163 3 94050G 1 Piece Pressure gauge 0-10 bar
164 3 94050B 1 Piece Pressure gauge 0-100 bar
165 3 TN 94003 1 Piece Pressure gauge 0-600 bar
166 3 94050H 2 Pieces Stop valve 2 pieces
167 3 94050C 1 Piece Adapter 1 piece
nil 1 - Tool general chain block -
nil 2 - 1 Piece Shackle -
170 3 94018A 4 Pieces Shackle Max. loading 3250 kg
171 3 94018B 4 Pieces Shackle Max. loading 4750 kg
172 3 94018B 4 Pieces Shackle Max. loading 8500 kg
nil 2 - 1 Piece Chain -
174 3 94019A 1 Piece Chain X = 1323 mm
nil 2 - 1 Piece Chain -
176 3 94019B 1 Piece Chain X = 1089 mm
nil 2 - 1 Piece Tool general chain block -
178 3 TN 94085 2 Pieces Lever chain hoist LX LX005
179 3 TN 94086 2 Pieces Lever chain hoist L5 LB016
X62DF
AA00-0000-00AAA-941A-C
Maintenance Manual Standard tools
Winterthur Gas & Diesel Ltd.
- 857 - Issue 002 2020-10
