Pos. Ind. Part No. Quantity Description Remark
nil 1 - Tool tc failure - ABB A175 For number of TC 2
534 2 94653 1 Piece Tool tc failure -
535 3 94653D-A175 2 Pieces Cover For TC 1 and TC 2; X = 680 mm; Ø =
600 mm; Cover to Turbocharger
outlet
536 3 94653C-A175 1 Piece Cover X = 900 mm; Ø = 820 mm; Cover to
scavenge air receiver
537 3 94653B-A175 1 Piece Cover X = 726 mm; Ø = 630 mm; Cover to
turbocharger inlet
538 3 94653A-A175 1 Piece Cover X = 948 mm; Ø = 820 mm; Cover to
exhaust manifold outlet
nil 1 - Tool tc failure - MHI MET60 For number of TC 2
540 2 94653 1 Piece Arrangement of covers -
541 3 94653A-M60 1 Piece Cover Y = 680 mm; Ø = 600 mm; Cover to
exhaust manifold outlet
542 3 94653B-M60 1 Piece Cover Y = 680 mm; Ø = 600 mm; Cover to
turbocharger inlet
543 3 94653C-M60 1 Piece Cover Y = 640 mm; Ø = 560 mm; Cover to
scavenge air receiver
544 3 94653B-M60 2 Pieces Cover For TC 1 and TC 2; Y = 600 mm; Ø =
520 mm; Cover to turbocharger outlet
nil 1 - Tool tc failure - ABB A265 For number of TC 2
546 2 94653 1 Piece Arrangement of covers -
547 3 94653C-A265 2 Pieces Cover For TC 1 and TC 2; X = 555 mm; Ø =
475 mm; Cover to turbocharger outlet
and Scavenge air receiver
548 3 94653A-A265 1 Piece Cover X = 680 mm; Ø = 600 mm; Cover to
exhaust manifold outlet
549 3 94653B-A265 1 Piece Cover X = 680 mm; Ø = 600 mm; Cover to
turbocahrger inlet
nil 1 - Tool tc failure - MHI MET66 For number of TC 1
551 2 94653 2 Pieces Arrangement of covers -
552 3 94653B-M66 2 Pieces Cover Y = 668 mm; Ø = 580 mm; Cover to
turbocharger outlet
nil 1 - Tool tc failure - ABB A275 For number of TC 2
554 2 94653 1 Piece Arrangement of covers -
555 3 94653A-A275 2 Pieces Cover X = 890 mm; Ø = 800 mm; Cover to
exhaust manifold outlet and
turbocharger inlet
556 3 94653D-A275 2 Pieces Cover For TC 1 and TC 2; X = 736 mm; Ø =
656 mm; Cover to turbocharger outlet
557 3 94653C-A275 1 Piece Cover X = 780 mm; Ø = 700 mm; Cover to
scavenge air receiver
nil 1 - Tool tc failure - A180 For number of TC 2
559 2 94653 1 Piece Arrangement of covers -
560 3 94653C-A180 1 Piece Cover X = 763 mm; Ø = 686 mm; Cover to
scavenge air receiver
561 3 94653A-A180 1 Piece Cover X = Ø = 872 ; Cover to exhaust
manifold outlet
562 3 94653B-A180 1 Piece Cover X = 952 mm; Ø = 872 mm; Cover to
turbocharger inlet
563 3 94653D-A180 2 Pieces Cover For TC 1 and TC 2; X = 763 mm; Ø =
686 mm; Cover to turbocharger outlet
X62DF
AA00-0000-00AAA-941A-C
Maintenance Manual Standard tools
Winterthur Gas & Diesel Ltd.
- 866 - Issue 002 2020-10
