1128600 SmartPAC 2 with WPC 2000 Integration User Manual
2-62 Installation
Table 2-19. DiPro Sensor Interface (DSI) 2 to SmartPAC 2 Wiring, Sensors 9-16
Wire color* 2nd DSI 2 (TB2) DiProPAC (TB554)
Pin # Pin Designation Pin # Pin Designation
Brown 1 SENSOR 1 292 SENSOR 9
Red 2 SENSOR 2 293 SENSOR 10
Orange 3 SENSOR 3 294 SENSOR 11
Yellow 4 SENSOR 4 295 SENSOR 12
Green 5 SENSOR 5 296 SENSOR 13
Blue 6 SENSOR 6 297 SENSOR 14
Violet 7 SENSOR 7 298 SENSOR 15
Gray 8 SENSOR 8 299 SENSOR 16
No connection 300 Sensor power
Black 9 GND 301 GND
10 GND No connection
11 +5 VDC No connection
Shield Terminate drain wire to ground
stud
Terminate drain wire to ground
stud
* Your colors may be different.
Table 2-20. DiPro Sensor Interface (DSI) 2 to SmartPAC 2 Wiring, Sensors 17-24
Wire color* 3rd DSI 2 (TB2) DiProPAC (TB555)
Pin # Pin Designation Pin # Pin Designation
Brown 1 SENSOR 1 180 SENSOR 17
Red 2 SENSOR 2 181 SENSOR 18
Orange 3 SENSOR 3 182 SENSOR 19
Yellow 4 SENSOR 4 183 SENSOR 20
Green 5 SENSOR 5 184 SENSOR 21
Blue 6 SENSOR 6 185 SENSOR 22
Violet 7 SENSOR 7 186 SENSOR 23
Gray 8 SENSOR 8 187 SENSOR 24
No connection 188 Sensor power
Black 9 GND 189 GND
10 GND No connection
11 +5 VDC No connection
Shield Terminate drain wire to ground
stud
Terminate drain wire to ground
stud
* Your colors may be different
