1128600 SmartPAC 2 with WPC 2000 Integration User Manual
2-108 Installation
Foot Switch Test
This test, which should be run only if you have an optional Foot Switch, verifies that your
Foot Switch is operating properly. To perform the test, do the following, referring to
Figure 2-41 for LED locations and Input Status, page 4-44 for instructions in how to access
the Input Status screens:
1. On the SmartPAC 2 front panel:
• Make sure the Program/Run key switch is set to RUN.
• Turn the Stroke Select key switch of OFF.
• Select FOOT on the Mode Select Menu (see page 6-40)
• Turn the Stroke Select key switch to SINGLE STROKE.
Verify that the “S.S. SEL” and “FOOT N/C” items on the WPC Buttons and Switches
Input Status screen are ON (see Figure 4-26, page 4-45).
2. Make sure that option switch 3 on the WPC 2000 Main Processor board is set to OPEN, its
default setting (see Enabling Foot Control in a Foot Switch, page 4-37).
3. Power down, then power back up the WPC 2000, if necessary, to enable the settings
change. The WPC 2000 is now in Foot Trip mode, the press stroking each time the Foot
Switch is depressed.
INJURY DURING TESTING
• Keep all personnel away from the press during testing.
• Be sure there is no die or other tooling in the press during testing.
Failure to comply with these instructions will result in death or serious injury.
MISSING SAFEGUARDS
Install a light curtain for use with the Foot Switch option. A light curtain is required for using the
Foot Switch.
Failure to comply with these instructions will result in death or serious injury.
These instructions refer to the Auto Carry-up Angle, which is factory set to one of the following
values:
• 170° if the press does not have a light curtain
• 149° if the press does have a light curtain
Refer to Setting the Auto Carry-up Angle, page 4-28 for information about the Auto Carry-up
feature.
