SmartPAC 2 with WPC 2000 Integration User Manual 1128600
Run Mode 6-33
TOOL INFORMATION
(RUN – TOOL INFORMATION)
This item enables you to change information about the loaded tool that was entered in
Program mode (see TOOL INFORMATION, page 5-50). Adjustments are made on the Tool
Number Information screen, which is shown in Figure 6-26.
To change tool information, do the following:
1. Select TOOL INFORMATION on the Main Run Menu. The Tool Number Information
screen displays.
IF INFO IS CENTER INSTALLED
If you have ordered Info Center as an installed option, the TOOL INFORMATION item will not
appear on the Main Run Menu. Instead, INFO CENTER will be displayed. Documentation of the
Info Center option is available at
www.smartpac2.com/SmartView/InfoCenterSetupHelp.htm
• The Tool Information screen provides a convenient place to record information about the tool. It
does not control any aspect of press operation.
• This feature is not available if you have the optional PLC interface installed.
For help with the Tool Information screen, press the HELP key when the screen is displayed.
Figure 6-26. Tool Number Information Screen
