SmartPAC 2 with WPC 2000 Integration User Manual 1128600
Fault Messages 7-23
Internal Memory Failures
- or -
Problem: There is a problem with the main or second processor on the WPC 2000 Main
Processor board. The board may need to be serviced or replaced. Errors are as
follows:
Remedy: Press RESET. If the error persists, contact Wintriss Tech. Support for assistance
or replacement of the Main Processor board or firmware chip.
Counter Preset Reached Messages
“Good parts counter preset reached”
Problem: The value set for the parts counter has been reached. The press should stop at top
dead center.
Remedy: Press RESET to clear the message. If your part run is complete, you need to
change tooling, material, etc. before you re-start the press.
F90* through F98*
H90* through H98*
F90 or H90 Program memory checksum 1 is incorrect
F91 or H91 Program memory checksum 2 is incorrect
F95 or H95 Angle table memory checksum is incorrect
F96 or H96 RAM memory failed memory test
F97 or H97 No angle setup is loaded
F98 or H98 The option switch image changed during operation
F99 or H99 +24 Vdc failed, or the fuse blew
INFORMATION ON ERROR NUMBERS EQUAL TO OR GREATER THAN 120
Error numbers equal to or greater than 120 are covered in the WPC 2000 Option 2 Manual
(1130700) and the WPC 2000 Option 2 Additional Inputs Only Instruction Sheet (1141900).
When this message appears, the good parts count is automatically reset to 0.
