1128600 SmartPAC 2 with WPC 2000 Integration User Manual
J-10 Option 1 User Inputs
2. Press the function key (i.e., F4, F5, or F6) corresponding to the group of user inputs (i.e.,
Group 1, Group 2, or Group 3) within which the user input whose status you want to view
falls. The WPC Interlock Input Status screen for that user input group displays (see
Figure 4-28, page 4-46, which uses the Group 1 screen as an example).
The status of all user inputs (OFF or ON) is shown in the STATUS column. Inputs that are
ON are highlighted. OFF inputs are not highlighted. In addition, an OFF input may
generate the fault code specific to that input on the SmartPAC 2 display. “Unused” inputs
show an OFF status but do not generate a fault code display.
Troubleshooting
Table J-4 shows the fault code associated with each Option 1 user input that appears on your
SmartPAC 2 display when there is a problem with the auxiliary equipment that input is
connected to. An additional fault code is documented following the table.
To correct the problem that caused the fault code to display, check the equipment and wiring
connected to that user input. When you have corrected the problem, reset SmartPAC 2 and
WPC 2000. If the problem recurs, contact Wintriss Tech. Support.
Table J-4. WPC 2000 Option 1 Fault Codes
Fault Code User Input Stop Type Pin #
Terminal for
Jumper Connection
120 User 12 Top-stop 433 Ground
121 User 13 Top-stop 434 Ground
122 User 14 Top-stop 435 Ground
123 User 15 Top-stop 436 Ground
124 User 16 Top-stop 440 Ground
125 User 17 E-stop 441 Ground
126 User 18 E-stop 442 Ground
127 User 19 E-stop 443 Ground
128 User 20 E-stop 444 Ground
129 User 21 E-stop/Lockout 445 Ground
130 User 22 Top-stop 448 +24 Vdc
131 User 23 Top-stop 449 +24 Vdc
132 User 24 Top-stop 450 +24 Vdc
133 User 25 Top-stop 451 +24 Vdc
134 User 26 Top-stop 455 +24 Vdc
135 User 27 E-stop 456 +24 Vdc
136 User 28 E-stop 457 +24 Vdc
137 User 29 E-stop 458 +24 Vdc
138 User 30 E-stop/Lockout 459 +24 Vdc
139 User 31 E-stop 460 +24 Vdc
