SmartPAC 2 with WPC 2000 Integration User Manual 1128600
Installation 2-85
Installing Revised Firmware in WPC 2000
To install revised firmware in WPC 2000, follow these steps:
1. Record the following WPC 2000 settings, using the Press Parameters Setup Sheet at the
back of the manual:
• Stop-time Limit (see page 4-30)
• Auto Carry-up Angle (see page 4-28)
• Top-stop Angle (see page 4-28)
• Micro-inch Time (see page 4-29)
• Cam On/Off settings (see page 6-19)
• Counter Preset (page 6-8)
• Counter (if necessary–see page 6-8)
2. Turn off power to WPC 2000.
3. Making sure that you are grounded, open the WPC 2000 enclosure and locate firmware
chips A (labelled “U111”) and B (labelled “U134”) on the Main Processor board (see
Figure 2-14, page 2-28). Note that each chip has a white label and a semi-circular notch at
one end. The notch on the chip faces in the same direction as the notch on its socket.
MACHINE MALFUNCTION AFTER INSTALLING REVISED SOFTWARE
Perform the final checkout (see page 2-87) tests after performing the firmware installation.
Failure to comply with these instructions could result in death or serious injury.
ELECTRIC SHOCK OR HAZARDOUS ENERGY
• Disconnect main power before installation.
• Remove all power to the press, press control, and other equipment used with the press.
• Remove all fuses and “tag out” per OSHA 1910.147 Control of Hazardous Energy (Lockout/
Tagout).
• Ensure that installation is performed by qualified personnel.
• Complete all installation procedures before connecting to the AC power source.
Failure to comply with these instructions will result in death or serious injury.
STATIC DISCHARGE DAMAGE TO CHIP
Ground yourself before touching circuit boards or chips by touching a large metal object
such as the press. Static electricity can destroy electronic components.
Failure to comply with these instructions could result in property damage.
To Next Page
