1128600 SmartPAC 2 with WPC 2000 Integration User Manual
H-26 Reporting Downtime and Scrap to SFC
2. When the Good Parts Entry window (like the window shown in Figure H-15) displays,
key in the number of good parts you want to add (1,000 parts maximum), and press
ENTER. A Confirmation window like the one shown in Figure H-19 displays.
3. Press the Up () cursor key to confirm that you want to change the Good Parts counter
value. You are returned to the Counters screen with your adjustment reflected in the
GOOD PARTS COUNT field.
Adjusting the Good Parts Counter in Program Mode
To increase the Good Parts count in Program mode, do the following:
1. On the Counters screen in Run mode, press RESET to return to the Main Run Menu.
2. Turn the Program/Run key to “PROG” to display the Main Program Menu.
3. Select “GO TO THE TOOL MANAGER” to display the Tool Manager screen.
4. Press F4 (Edit Tool) with the loaded tool selected to display the Tool Program Menu.
5. Select COUNTERS to display the Counters screen.
6. Perform steps 1 through 3 of the procedure for adjusting the Good Parts counter in Run
mode, above.
Figure H-19. Good Parts Counter Adjustment Confirmation Window
If you attempt to enter a value greater than 1,000 or one that reduces (rather than increases) the
Good Parts count, an error message will display briefly.
In Program mode, you can increase the Good Parts count in increments greater than 1,000.
