1128600 SmartPAC 2 with WPC 2000 Integration User Manual
J-12 Option 1 User Inputs
Option 1 User Input Setup Sheet
* Option 1 user inputs are set to E-stop by default. Settings can be changed on the Press Control User Interlock Menu
(see page J-8).
Option 1 inputs 12-31 can be programmed as E-stop, Top-stop, E-stop/Lockout, Top-stop/Lock-
out,
and Unused. Input pairs 32/33, 34/35, 36/37, and 38/39 can be set to E-stop or E-stop/ Lockout.
User Input
Fault
Code Stop Type * Pin #
Terminal
for Jumper
Connection
Name of Auxiliary
Equipment
User 12 120 433 Ground
User 13 121 434 Ground
User 14 122 435 Ground
User 15 123 436 Ground
User 16 124 440 Ground
User 17 125 441 Ground
User 18 126 442 Ground
User 19 127 443 Ground
User 20 128 444 Ground
User 21 129 445 Ground
User 22 130 448 +24 Vdc
User 23 131 449 +24 Vdc
User 24 132 450 +24 Vdc
User 25 133 451 +24 Vdc
User 26 134 455 +24 Vdc
User 27 135 456 +24 Vdc
User 28 136 457 +24 Vdc
User 29 137 458 +24 Vdc
User 30 138 459 +24 Vdc
User 31 139 460 +24 Vdc
User 32 paired
with User 33
140, 144
431 +24 Vdc
438 +24 Vdc
User 34 paired
with User 35
141, 145
432 +24 Vdc
439 +24 Vdc
User 36 paired
with User 37
142, 146
452 +24 Vdc
461 +24 Vdc
User 38 paired
with User 39
143, 147
453 +24 Vdc
462 +24 Vdc
