SmartPAC 2 with WPC 2000 Integration User Manual 1128600
Option 1 User Inputs J-11
F148 Fault
Problem: If the message “F148 OPTION BOARD NOT CORRECT” appears on your
SmartPAC 2 display, it means either that the Option 1 board is not seated properly
in the WPC 2000 board or has been removed from the WPC 2000 board.
Remedy: Make sure that the Option 1 board is seated firmly and that the screws securing it
to the WPC 2000 board are tight. If the Option 1 board has been removed,
re-initialize WPC 2000 and cycle power to the SmartPAC 2 control.
To re-initialize WPC 2000, put the SmartPAC 2 into Initialization mode, then select, in
succession, “PRESS CONTROL” on the Main Initialization Menu, “PRESS
PARAMETERS” on the WPC Initialization Menu, and, finally, “INITIALIZE
PARAMETERS” on the Press Control Parameter Menu.
140, 144
User 32 paired
with User 33
E-stop 431 +24 Vdc
E-stop 438 +24 Vdc
141, 145
User 34 paired
with User 35
E-stop 432 +24 Vdc
E-stop 439 +24 Vdc
142, 146
User 36 paired
with User 37
E-stop/Lockout 452 +24 Vdc
E-stop/Lockout 461 +24 Vdc
143, 147
User 38 paired
with User 39
E-stop/Lockout 453 +24 Vdc
E-stop/Lockout 462 +24 Vdc
Removal of the Option 1 board should only be performed after careful consideration of safety
implications. If you have wired and programmed cross-checked user inputs on the Option 1 board,
removal of the board could render press operation hazardous.
When you re-initialize WPC 2000, all press control parameters (e.g., option switch settings, brake
monitor settings, etc.) are reset to their default values. To avoid losing data you have painstakingly
entered, copy existing press control parameters to a table so you can replace them when WPC
2000 is re-initialized.
Table J-4. WPC 2000 Option 1 Fault Codes (Cont.)
Fault Code User Input Stop Type Pin #
Terminal for
Jumper Connection
To Next Page
