SmartPAC 2 with WPC 2000 Integration User Manual 1128600
Run Mode 6-53
Operating the Press in Bar Mode
To operate the press in Bar mode, you must have the Bar Mode Control option. To activate
Bar mode and bar the press, do the following:
1. Make sure the Program/Run key switch is set to RUN.
2. Turn the Stroke Select key switch to OFF.
3. Select “TWO HAND” on the Mode Select Menu (see page 6-40).
4. Turn the Stroke Select switch to “INCH.”
5. Turn off the press motor.
6. On the Bar Control enclosure (see Figure 2-22, page 2-45), turn the Select switch to
“ON.”
7. When the flywheel stops turning, press the Operate button on the Bar Control enclosure.
8. Bar the press using a spring-loaded bar.
9. If an F26 error appears in the display, press the Reset/Select button to clear it, and
continue with the barring operation.
INJURY WHEN USING BAR MODE
• Keep all personnel away from the press while it is being barred
• Use a spring-loaded turnover bar when you bar the press.
Failure to comply with these instructions will result in death or serious injury.
When barring the press, do not rotate the flywheel too quickly. If the crankshaft moves
faster than 6 SPM, WPC 2000 will stop the ram and fault code F26 will appear on the
SmartPAC 2 display. Press the RESET key to continue barring the press.
