Wintriss SmartPAC 2 - Figure 2-32. Cam Outputs Board

1128600 SmartPAC 2 with WPC 2000 Integration User Manual
2-66 Installation
Figure 2-32. Cam Outputs Board
Cam 4
Solid State Relays
Channels 5-8
LEDs for channels
Connection to
press control
Relay 1
K301
Relay 2
K302
Relay 3
K303
Relay 4
K304
Relay 5
K305
Relay 6
K307K309K311
Use only one relay
(mechanical or solid state)
for each channel
Mechanical
Relays
TB303
TB302
CHAN 1CHAN 2CHAN 3CHAN 4CHAN 5CHAN 6CHAN 7CHAN 8
Fuses
DS301
TB301
Connect to loads
to be controlled
Cam 1Cam 3 Cam 2Counter
on - 200
off - 250
o
o
