SmartPAC 2 with WPC 2000 Integration User Manual 1128600
Fault Messages 7-13
Input Buffer Test Failures
Problem: The following errors may occur when WPC 2000 performs input buffer tests,
which compare the input data provided by processor A with the data provided by
processor B. When the input data doesn’t match, an error is generated.
Remedy: Try pressing RESET. If error persists, contact Wintriss Tech. Support.
Air Pressure Limits Exceeded
Problem: Clutch Air Pressure is below the setpoint established in SmartPAC 2 Initialization.
Remedy: Check your Clutch Air Pressure level. You may need to adjust the Main Air Limit
setting (see page 4-29 for instructions).
Problem: Counterbalance Air Pressure is outside the Counterbalance Setpoint tolerance
established in SmartPAC 2 Initialization.
Remedy: Check your Counterbalance Air Pressure level. You may need to adjust the
Counterbalance +/- setting (see page 4-29 for instructions).
F41* through F44*
F41 Input buffer 1 check incorrect. This test checks system air pressure and
motor forward inputs and user inputs 1 and 8.
F42 Input buffer 2 check incorrect. This test checks remote reset, motor
reverse, and bar mode selector inputs.
F43 Input buffer 3 check incorrect. This test checks the DSV monitor input and
user inputs 2 and 9.
F44 Input buffer 4 check incorrect. This test checks the motor forward input
and user inputs 2, 5, 7, 8, and 10.
F45 or H45
F46 or H46
RAMPAC USERS
This error should not occur if you use RamPAC to monitor Counterbalance Air Pressure.
If you do get this error, make sure that RamPAC is wired correctly to its pressure sensor and that
WPC 2000 is wired correctly to its pressure switch. For pressure switch wiring instructions, refer to
page 2-15. Contact Wintriss Tech. Support if you need further assistance.
