1128600 SmartPAC 2 with WPC 2000 Integration User Manual
6-52 Run Mode
1. With “FOOT” highlighted on the Mode Select Menu,” press the Prior Act button on the
Operator Station, then, within 8 seconds, depress and hold the Foot Switch pedal. The
ram will complete the stroke and continue stroking until you release the Foot Switch, at
which point the press will return to Top-stop.
As long as the Foot Switch is depressed, the press will continue to stroke but will stop if
one of the following events occurs:
• You press the Top Stop button
• You press the Emergency Stop button
• A system fault is detected
• The light curtain is blocked during the non-muted portion of the stroke
Operating the Press in Automatic Continuous On-demand Mode
For information on using Automatic Continuous On-demand mode, call Wintriss Tech.
Support.
You must depress the Foot Switch within 8 seconds after you press the Prior Act button in order to
initiate Continuous mode operation. Otherwise, the press will not start. The Prior Act lamp
illuminates when you press the Prior Act button and turns off after 8 seconds.
If the press is Emergency-stopped, WPC 2000 automatically changes to Two-hand
Maintained Single-stroke mode and the “Interrupted Stroke” message flashes on the
SmartPAC 2 display. To clear the “Interrupted Stroke” message, press and hold both Run/
Inch buttons on the Operator Station to complete the stroke and return the ram to Top
Stop.
IMPROPER SAFEGUARDING
Ensure that the machine guarding system is installed and maintained according to OSHA standard
1910.217, ANSI B11.1, ANSI B11.19 and any other regulations and standards that apply. Ensure
that guarding is properly installed to prevent access to the machine over, under or around any
guarding device.
Failure to comply with these instructions will result in death or serious injury.
PRESS STARTING UNEXPECTEDLY
• Ensure that light curtains and other safeguards are properly installed and operating to protect
operators when using Automatic Continuous On-demand mode, in which a stroke can occur
unexpectedly.
Failure to comply with these instructions will result in death or serious injury.
