1128600 SmartPAC 2 with WPC 2000 Integration User Manual
4-12 Initialization Mode
4. If none of the names in the list seems suitable but you still want to name the cam channel,
you can select “CUSTOM NAME.” If you do so, the Alphabetic Entry window (see
Figure 4-6, page 4-10) displays.
5. Key in a “custom” cam channel name, following the directions in the Alphabetic Entry
window, then press F6 to accept your entry. You are returned to the Cam Channel Name
Menu with the “custom” name you selected displayed to the right of the selected channel.
To cancel your selection, press RESET.
6. When you are finished naming channels, press RESET to return to the Main Initialization
Menu.
AUTO ADVANCE and Slow RPM (Optional)
(INITIALIZATION – AUTO ADVANCE)
This item, which appears on the Main Initialization Menu only when ProCamPAC is installed,
enables you to set parameters that control the timing for up to two cam channels that are
programmed as Auto Advance. You make these settings on the Auto Advance Menu (see
Figure 4-9), which displays when you select the AUTO ADVANCE item.
You can use a separate computer keyboard to enter cam channel names. See page 4-68.
Cam channel names do not replace channel numbers. They simply provide a way to
identify channel numbers by their function.
Figure 4-9. Auto Advance Menu
