SmartPAC 2 with WPC 2000 Integration User Manual 1128600
Installation 2-33
inputs. After you have wired the inputs you will use, be sure to bypass all the unused inputs
by connecting them to +24 Vdc or ground.
* Stop types for all inputs except input pair 10/11 are set to E-Stop by default; input pair 10/11 is set to E-Stop/Lockout.
All inputs except input pair 10/11 can be reconfigured by the user. If you have SmartPAC 2 firmware version 3.32 or
higher and WPC 2000 firmware version 1.70 or higher, an additional stop type option, Top-stop/Lockout, is available
for user inputs 1-7. To set these inputs to Top-stop/Lockout or to change the stop type setting for any user input, see
page 4-24.
You can add up to 20 more non-control-reliable user inputs and up to 4 more control-reliable,
cross-checked user inputs to your WPC 2000 by purchasing the Option 1 “daughter” board,
which you install on the WPC 2000 Main Processor board. If you are interested in this
product, contact your local Wintriss representative or call Wintriss Tech. Support. To install,
wire, program, monitor, and troubleshoot the Option 1 board, refer to Appendix J.
You can display the status of all user inputs in SmartPAC Initialization mode. See Input
Status, page 4-44.
Table 2-6. WPC 2000 User Inputs: Stop Types, Fault Codes, and Wiring Connections
User Input
(Interlock) Stop Type *
Pin
#
Jumper
Connection
(Bypass)
Fault
Code
Name of Auxiliary
Equipment
User 1 21 +24 Vdc 51
User 2 82 +24 Vdc 52
User 3 71 +24 Vdc 53
User 4 83 Ground 54
User 5 72 Ground 55
User 6 84 Ground 56
User 7 73 Ground 57
User 8 paired
with 9
85 Ground
58, 17
User 9 paired
with 8
74 Ground
User 10 paired
with 11
E-stop/
Lockout
86 Ground
50, 18
User 11 paired
with 10
18 Ground
If you do not bypass the unused inputs, WPC 2000 will not work properly.
