1128600 SmartPAC 2 with WPC 2000 Integration User Manual
2-46 Installation
Wiring Automatic Single-stroke
Automatic Single-stroke is an operating mode that enables the operator to automate a manual
press using a feeding device or robot. To wire the Automatic Single-stroke actuating
mechanism, refer to Table 2-14 and Figure 3 at the back of the manual.
Though an SPDT contact is shown in Figure 3, you can also use solid state switches
(proximity switches, for example) or outputs from a programmable logic controller (PLC).
To make sure that the contacts are clear and reliable, the switch or relay should be new and
unused.
You set the Prior Act time for Automatic Single-stroke with option switch 5 (see page 4-38).
To operate the press in this operating mode, refer to page 6-49.
Wiring Automatic Continuous On-demand
Contact Wintriss Tech. Support for information on using this operating mode.
PRESS STARTING UNEXPECTEDLY
• Ensure that light curtains and other safeguards are properly installed and operating to protect
operators when using Automatic Single-stroke. Since the external trigger starts the stroke, a
stroke can occur unexpectedly.
• Ensure that guarding is properly installed to prevent access to the machine over, under, or
around any guarding device.
Failure to comply with these instructions will result in death or serious injury.
Table 2-14. Automatic Single-stroke Wiring Connections
WPC 2000 Main Processor Bd.
Pin #
Foot Switch
Contacts
15 N/C input
5 N/O input
+24 Vdc (e.g., #37) Common
PRESS STARTING UNEXPECTEDLY
• Ensure that light curtains and other safeguards are properly installed and operating to protect
operators when using Automatic Continuous On-demand mode, in which a stroke can occur
unexpectedly.
• Ensure that guarding is properly installed to prevent access to the machine over, under, or
around any guarding device.
Failure to comply with these instructions will result in death or serious injury.
