SmartPAC 2 with WPC 2000 Specifications
SmartPAC 2 with WPC 2000 specifications are shown in Table 1-1.
Table 1-1. SmartPAC 2 with WPC 2000 Specifications
Enclosures
SmartPAC 2 Enclosure
12.76 x 11.53 x 5.28 in. (324 x 293 x 134 mm), NEMA 12, shock-mounted.
Weight: 17.4 lbs.
SmartPAC 2 Panel mount
12.3 x 11.3 in. (312 x 287 mm)
WPC 2000 Enclosure
14.00 x 19.62 x 7.00 in. (355.6 x 498.3 x 177.8 mm), NEMA 12,
shock-mounted.
WPC 2000 without Enclosure
Allow 15.5 x 15.5 x 5.5 in. (394 x 394 x 140 mm) for installation.
Equipment
(Available from
Wintriss
Controls)
Resolver
0.75 in. (19 mm) keyed shaft. Rated shaft loading: 200 lb. axial, 200 lb. radial.
Operator Station
NEMA 12. Includes two palm buttons, Top-stop, Emergency-stop, and Prior
Act buttons, and palm time and mute lamps. Pre-wired; unwired version also
available.
Dual Safety Valve (DSV)
Available in 0.75 in. (19 mm) or 1 in. (25 mm) Ross DM2 models.
Air Pressure Switch or Sensor
Switch: 12-150 PSI. Sensor: 0-200 PSI, 1-6 Vdc, excitation 24 Vdc. Monitors
clutch air supply pressure.
Electrical
SmartPAC 2 Input
115/230 ± 10% Vac 50/60 Hz, 50 VA
Input Check Circuit
12-250 Vac or Vdc
WPC 2000 Input
100-240 ± 10% Vac (universal switching), 50/60 Hz., 75 VA
WPC 2000 Output
24 ± 1% Vdc, 200 mA maximum for customer use including auxiliary outputs.
Power Requirements If Not Using Wintriss AC Power Supply
24 ± 5% Vdc, 2 A. Must be certified to CSA C22.2 No. 234 Standard.
Oper. Temp.
32° to 122° F (0° to 50° C)
Speed
7-800 SPM; 14-1600 SPM optional at reduced accuracy (see SmartPAC 2
Options, below)
