SmartPAC 2 with WPC 2000 Integration User Manual 1128600
Introduction 1-13
Accuracy
± 2/3° (± 1.33° for high speed version–see SmartPAC 2 Options, below)
Counters
Good parts, strokes, 3 batch with presets (7 digits)
Number-of-hits-on-tool counter: counts all hits on tool; resettable to 0 after
maintenance
Display
10.4 in. (264 mm) color active matrix TFT liquid crystal display (LCD)
Brake Warning LED, Power LED
Memory
Allows storage of settings for 200 tools
SmartPAC 2
Inputs/Outputs
Inputs for resolver, input check circuit, remote reset
USB, PS/2 and Ethernet RJ-45 connectors
Outputs for top stop, emergency stop: ratings 0-4 A resistive @ 120V max (AC
or DC); Normally open–Held closed. Fault condition or power off opens
relay(s)
WPC 2000
Inputs
Resolver
Overrun limit switch
Two operator stations
DSV monitor
Air pressure switch or sensor (???)
Two pressure sensors: range, 0-200 psi; output, 1-6 Vdc; excitation, 12 Vdc.
Additional
WPC 2000
Inputs
Motor
Forward and reverse contacts
Shadow Light Curtains (2)
Checks proper functioning at every stroke initiation and stop.
Customized Status Codes
Seven for E-stop, Top-stop, or E-stop/Lockout
Two cross-checked pairs, one for E-stop or E-stop/Lockout, the other for
E-stop/Lockout only
WPC 2000
Outputs
DSV
Two monitored relays, rated 4 A @ 120 Vac, for E-stopping and Top-stopping
press.
Lockout
One monitored relay, rated 4 A @ 120 Vac, for de-energizing motor and other
devices under critical conditions.
Auxiliary Stop Output
Provides a signal to stop auxiliary equipment during an interrupted stroke.
Communications
Connects via Ethernet to local area network; data viewed via the Internet using
SmartView remote viewing utility; allows backup of programmed tool settings
to a network drive.
SmartPAC 2
Options
DiProPAC provides up to 32 die protection sensor inputs
Power for electronic sensors (NPN only): 15 Vdc min., 100 mA total
DiPro Sensor Interface, DSI 2*: 5.88 x 5.41 x 3.42 in. (149 x 137 x 87 mm)
DiProPAC sensor-disabled output: open collector, 8 mA max.
Table 1-1. SmartPAC 2 with WPC 2000 Specifications (Cont.)
