SmartPAC 2 with WPC 2000 Integration User Manual 1128600
Installation 2-107
4. Press the Emergency Stop button on the Operator Station. The ram should stop
immediately, the F13 fault code should appear in the LED display, and the Interrupted
Stroke message should display. If these conditions are not present, check the wiring of the
Operator Station, particularly the E-stop wiring, and rerun this test from step 3. If the
conditions are still not present, call Wintriss Tech. Support.
5. Press and hold the Run/Inch palm buttons until the press returns to top dead center.
6. Press the Prior Act button and, before the indicator lamp goes out, press both Run/Inch
palm buttons, releasing them after bottom dead center on the first stroke. The press should
continue running.
7. Press the Top Stop button on the Operator Station. The ram should stop near top dead
center. If the ram does not stop at TDC, check the wiring of the Operator Station,
particularly the top-stop wiring, and correct any problems. Rerun this test from step 6. If
the ram still does not top-stop, call Wintriss Tech. Support.
8. If the die space is safeguarded with doors or gates with interlocking circuits, open a door/
gate and try starting the press. The press should not start and an F13 (see page 7-8), or
F17 or F18 (see page 7-9) error should display. Close the door/gate, reset the error, and
start the press. While the press is running, open the door/gate. The press should stop
immediately and display F13, F17, or F18. If the press does not stop, check the wiring of
the interlock switch and the switch itself for proper functioning.
9. Go to the next applicable test.
RESET EMERGENCY-STOP BUTTON AFTER USE
The Emergency-stop button is not spring-loaded. You must pull it up to its original position
to reset the Emergency-stop (F13) fault.
When a stroke is interrupted, WPC 2000 automatically switches to Two-hand Maintained
Single-stroke mode for the remainder of the stroke.
