1128600 SmartPAC 2 with WPC 2000 Integration User Manual

I-24 Reporting Downtime and Scrap to LETS

Adjusting the Good Parts Counter in Program Mode

To increase the Good Parts count in Program mode, do the following:

1. On the Counters screen in Run mode, press RESET to return to the Main Run Menu.

2. Turn the Program/Run key to “PROG” to display the Main Program Menu.

3. Select “GO TO THE TOOL MANAGER” to display the Tool Manager screen.

4. Press F4 (Edit Tool) with the loaded tool selected to display the Tool Program Menu.

5. Select COUNTERS to display the Counters screen.

6. Perform steps 1 through 3 of the procedure for adjusting the Good Parts counter in Run

mode, above.

In Program mode, you can increase the Good Parts count in increments greater than 1,000.

NOTICE
