Xerox Phaser 4600

04/2016
2-14
Phaser 4600/4620/4622 Printer Service Manual
03-480-00, 03-600-00
Revised
2 Status Indicator RAPS
3. Control Board, PL 7.25 Item 18
4. MCU Board, PL 3.10 Item 3
03-600-00 Memory Failure RAP
03-600-00 A memory access failure has been detected within the Network Controller.
BSD-Reference: WD 9
Initial Actions
• Cycle system power.
• Reseat or remove optional memory.
Procedure
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer
supply while performing tasks that do not need electricity. Electricity can cause death or
injury. Moving parts can cause injury.
Cycle system power. The error message is displayed.
YN
Complete.
Remove optional memory, if installed and retest. The error message is displayed.
YN
Replace the optional memory using the instructions provided.
Replace the IP Board, REP 3.6.
