04/2016
2-37
Phaser 4600/4620/4622 Printer Service Manual
08-110-00, 08-200-00
2 Status Indicator RAPS
Revised
08-110-00 Feed Motor Failure RAP
08-110-00 The Feed Drive Assembly failed to rotate.
BSD-Reference: WD 3
Initial Actions
• Check all interlocks.
• Check for obstructions blocking motor rotation.
Procedure
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer
supply while performing tasks that do not need electricity. Electricity can cause death or
injury. Moving parts can cause injury.
Cycle system power. The error message is displayed.
YN
Complete.
Select dC330 code 08-820 to test the Feed Drive. The Feed Drive Assembly rotates (on/
off).
YN
Remove the Right Cover (REP 28.2) and reseat CN12 on the MCU Board, then retest.
The Feed Drive Assembly rotates.
YN
Manually rotate the feed motor. The motor rotates freely.
YN
Check for obstructions in the media path. If no obstructions are present, replace
the Feed Drive Assembly, REP 4.4.
Replace the Feed Drive Assembly, REP 4.4.
Reassemble and perform SCP 6 Final Actions.
Replace these components in order until the error is corrected.
1. MCU Board, PL 3.10 Item 3
2. HVPS, PL 1.10 Item 1
08-200-00 Jam in Tray 2 RAP
08-200-00 Media remains in the Tray 2 Pick-up Assembly.
BSD-Reference: WD 3
Initial Actions
1. Check media condition.
2. Check for obstructions in the media path.
Procedure
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer
supply while performing tasks that do not need electricity. Electricity can cause death or
injury. Moving parts can cause injury.
Check the Nudger, Feed and Separator Rollers for excessive wear or contamination. The roll-
ers are undamaged and clean.
YN
Clean or replace the rollers.
Check for obstructions or debris in the media path. The media path is clear.
YN
Clear the media path of obstructions or debris.
Select dC330 code 08-100 to test the Take Away Sensor. The sensor signal changes (high/
low).
YN
Remove the Right Cover (REP 7.25) and reseat CN12 on the MCU Board, then retest.
The sensor signal changes.
YN
Replace the sensor.
Reassemble and perform SCP 6 Final Actions.
Select dC330 code 08-820 to test the Feed Clutch. The clutch is engaged (on/off).
YN
Remove the Right Cover (REP 28.2) and reseat CN12 on the MCU Board, then retest.
The clutch is engaged.
YN
Replace the Feed Clutch, REP 4.2.
Reassemble and perform SCP 6 Final Actions.
Select dC330 code 08-820 to test the Feed Drive Assembly. The Feed Drive Assembly
rotates (on/off).
YN
Remove the Right Cover (REP 28.2) and reseat CN12 on the MCU Board, then retest.
The Feed Drive Assembly rotates.
YN
Replace the Feed Drive Assembly, REP 4.4.
A B
To Next Page
