Phaser 4600/4620/4622 Printer Service Manual
08-450-00, 08-500-00
2 Status Indicator RAPS
Revised
YN
Remove the Right Cover (REP 7.25) and reseat CN7 on the Feeder Board, then retest.
The Feed Drive Assembly rotates.
YN
Replace the Feed Drive Assembly, REP 8.42.
Reassemble and perform SCP 6 Final Actions.
Replace these components in order until the error is corrected.
1. Feed Assembly, PL 8.40 Item 10
2. Pick Assembly, PL 8.20 Item 17
08-500-00 Jam 2 in Fuser Exit RAP
08-500-00 Media remains in the Fuser exit.
BSD-Reference: WD 4
Initial Actions
• Check the media.
• Check for obstructions in the media path.
• Check Fuser installation and condition.
Procedure
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer
supply while performing tasks that do not need electricity. Electricity can cause death or
injury. Moving parts can cause injury.
WARNING
Do not touch the Fuser while it is hot.
Check the Fuser Gear for damage. The gear is undamaged.
YN
Replace the Fuser Gear, REP 10.14.
Check the Fuser Heat and Pressure rollers. The rollers rotate freely and are clean
YN
Replace Fuser components as needed to restore proper operation:
• Heat Roller and Bearings, PL 10.11 Item 12
• Pressure Roller and Bearings, PL 10.11 Item 3
• Fuser Gear, PL 10.11 Item 14
Select dC330 code 10-400 to test the Fuser Drive Assembly. The Fuser Drive Assembly
rotates (on/off).
YN
Remove the Right Cover (REP 28.2) and reseat CN5 on the MCU Board, then retest.
The Fuser Drive Assembly rotates.
YN
Replace the Fuser Drive Assembly, REP 10.8.
Reassemble and perform SCP 6 Final Actions.
Refer to WD 8and select dC330 code 10-900 to test the Fuser Release Drive. The Fuser
Release Drive rotates (on/off).
YN
Remove the Left Cover (REP 28.3) and reseat CN1 on the Joint Board, then retest. The
Fuser Release Drive rotates.
YN
Replace the Fuser Release Drive, REP 10.17.
Reassemble and perform SCP 6 Final Actions.
A
To Next Page
