04/2016
2-42
Phaser 4600/4620/4622 Printer Service Manual
08-500-00, 08-600-00
Revised
2 Status Indicator RAPS
Test the Exit Drive Assembly. The Exit Drive rotates the exit rollers.
YN
Remove the Right Cover (REP 28.2) and reseat CN5 on the MCU Board. The exit roll-
ers rotate.
YN
Replace the Exit Drive Assembly, REP 10.32.
Reassemble and perform SCP 6 Final Actions.
Replace these components in order until the error is corrected.
1. Fuser, PL 10.10 Item 1 (110V) PL 10.10 Item 2 (220V)
2. MCU Board, PL 3.10 Item 3
08-600-00 Jam 0 in Duplex Unit RAP
08-500-00 Media jam at the rear of the Duplex Unit.
BSD-Reference: WD 3
Initial Actions
1. Check media condition.
2. Check the Rear Door latch.
3. Check for obstructions in the media path.
Procedure
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer
supply while performing tasks that do not need electricity. Electricity can cause death or
injury. Moving parts can cause injury.
Check the Duplex Unit transport components for damage or excessive wear. The rollers are
undamaged and clean.
YN
Clean or replace the Duplex Unit, PL 10.25 Item 26.
Check for obstructions or debris in the media path. The media path is clear.
YN
Clear the media path of obstructions or debris.
Check the Fuser thumbscrews. The Fuser thumbscrews are tight.
YN
Tighten the thumbscrews
Check the condition of the Duplex Unit Timing Belt, PL 10.25 Item 11. The belt is undam-
aged.
YN
Replace the Timing Belt, REP 10.19.
Check the exit gate and duplex roller. The exit gate and duplex roller move freely.
YN
Replace the Exit Assembly, REP 10.6.
Select dC330 code 04-230 to test the Duplex Drive Assembly. The Duplex Drive Assembly
rotates (on/off).
YN
Remove the Right Cover (REP 28.2) and reseat CN11 on the MCU Board, then retest.
The Duplex Drive Assembly rotates.
YN
Replace the Duplex Drive Assembly, REP 10.9.
Reassemble and perform SCP 6 Final Actions.
Replace the MCU Board, REP 3.4.
A
To Next Page
