09-003-00 Developer Motor Failure RAP
09-003-00 A drum motor error occurred in the Main Drive Assembly.
BSD-Reference: WD 4
Initial Actions
• Check the Drum Cartridge
• Cycle system power
Procedure
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer
supply while performing tasks that do not need electricity. Electricity can cause death or
injury. Moving parts can cause injury.
Cycle system power. The error message is displayed.
YN
Complete.
Check for obstructions or debris in the media path blocking drum rotation. Remove the Drum
Cartridge and clear any debris. The media path is clear.
YN
Clear the media path of obstructions or debris.
Select dC330 code 04-181 to test the drum motor. The motor rotates (on/off).
YN
Remove the Right Cover (REP 28.2) and reseat CN5 on the MCU Board, then retest.
The motor rotates.
YN
Replace the Main Drive Assembly, REP 4.1.
Reassemble and perform SCP 6 Final Actions.
Replace these components in order until the error is corrected.
1. Drum Cartridge, PL 9.10 Item 1
2. Main Drive Assembly, PL 4.10 Item 1
3. MCU Board, PL 3.10 Item 3
09-100-00 Toner Low RAP
09-100-00 Toner is almost empty. Possible low Toner, or toner unevenly distributed.
BSD-Reference: WD 7
Initial Actions
• Check Toner Cartridge life count.
• Gently agitate the cartridge.
Procedure
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer
supply while performing tasks that do not need electricity. Electricity can cause death or
injury. Moving parts can cause injury.
Check the Toner Cartridge life counter. Life count is at or near end of life.
YN
Cycle system power. The error message is displayed.
YN
Reassemble and perform SCP 6 Final Actions.
Replace the Toner Cartridge. The error message is displayed.
YN
Reassemble and perform SCP 6 Final Actions.
Replace the Joint Board, REP 9.8.
Replace the Toner Cartridge.
