Xerox Phaser 4600 Service Manual

04/2016
2-47
Phaser 4600/4620/4622 Printer Service Manual
09-200-00, 09-220-00, 09-210-00, 09-270-00
2 Status Indicator RAPS
Revised
09-200-00, 09-220-00 Toner Empty RAP
09-200-00 Toner Cartridge has reached end of life.
09-220-00 Toner Cartridge has reached end of life.
BSD-Reference: WD 7
Initial Actions
• Check Toner Cartridge life count.
• Replace the Toner Cartridge.
Procedure
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer
supply while performing tasks that do not need electricity. Electricity can cause death or
injury. Moving parts can cause injury.
Check the Toner Cartridge life counter. Life count at end of life.
YN
Cycle system power. The error message is displayed.
YN
Reassemble and perform SCP 6 Final Actions.
Replace the Toner Cartridge. The error message is displayed.
YN
Reassemble and perform SCP 6 Final Actions.
Replace the Joint Board, REP 9.8.
Replace the Toner Cartridge.
09-210-00, 09-270-00 Toner (ADC) Sensor Error RAP
09-210-00 ADC Sensor error.
09-270-00 ADC Sensor communications errors or failure.
BSD-Reference: WD 6
Initial Actions
• Cycle system power.
• Check for obstructions, debris, or accumulations of toner blocking the ADC Sensor and
shutter.
• Check Toner Cartridge life count.
• Check Drum Cartridge life count.
Procedure
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer
supply while performing tasks that do not need electricity. Electricity can cause death or
injury. Moving parts can cause injury.
Check the ADC Sensor shutter. Shutter motion is unobstructed.
YN
Clear the obstructions or repair the damage. The error message is displayed.
YN
Reassemble and perform SCP 6 Final Actions.
Replace the ADC Sensor, REP 9.2. The error message is displayed.
YN
Reassemble and perform SCP 6 Final Actions.
Remove the Right Cover (REP 28.2) and reseat CN15 on the MCU Board. The error
message is displayed.
YN
Reassemble and perform SCP 6 Final Actions.
Replace the MCU Board, REP 9.8.
Replace the ADC Sensor, REP 9.2. The error message is displayed.
YN
Reassemble and perform SCP 6 Final Actions.
Replace these components in order until the error is corrected.
1. HVPS, REP 1.4
2. Toner Cartridge
3. Drum Cartridge, PL 9.10 Item 1
4. MCU Board, PL 3.10 Item 3
