Xerox Phaser 4600 Service Manual

04/2016
2-51
Phaser 4600/4620/4622 Printer Service Manual
09-500-00, 09-508-00
2 Status Indicator RAPS
Revised
09-500-00 Toner Cartridge Not Installed RAP
09-500-00 The toner cartridge is not installed or the CRUM did not properly connect.
BSD-Reference: WD 7
Initial Actions
• Cycle system power.
• Replace the Toner Cartridge.
Procedure
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer
supply while performing tasks that do not need electricity. Electricity can cause death or
injury. Moving parts can cause injury.
Check the Toner Cartridge CRUM connection. The connection is clean and undamaged.
YN
Cycle system power. The error message is displayed.
YN
Reassemble and perform SCP 6 Final Actions.
Replace the Toner Cartridge. The error message is displayed.
YN
Reassemble and perform SCP 6 Final Actions.
Remove the Right Cover (REP 28.2) and reseat CN2 on the MCU Board. The error
message is displayed.
YN
Reassemble and perform SCP 6 Final Actions.
Replace the MCU Board, REP 9.8.
Remove the Left Cover (REP 28.3) and check the CRUM harness. The harness is con-
nected and undamaged.
YN
Repair or reconnect the harness.
Replace these components in order until the error is corrected.
1. Joint Board, PL 9.15 Item 7
2. MCU Board, PL 3.10 Item 3
09-508-00 Waste Toner Cartridge Near Full RAP
09-508-00 Waste Toner Cartridge is near end of life.
BSD-Reference: WD 7
Initial Actions
• Replace the Waste Toner Cartridge.
• Check for dust or toner blocking the sensor window on the cartridge.
Procedure
A replacement Waste Toner Cartridge is included with each new Toner Cartridge. When install-
ing a new Toner Cartridge, install the new Waste Toner Cartridge. When this error occurs,
replace both components.
