2-52
Phaser 4600/4620/4622 Printer Service Manual
09-589-00, 09-590-00
Revised
2 Status Indicator RAPS
09-589-00 Waste Toner Cartridge Full RAP
09-589-00 The Waste Toner Full Sensor indicates the cartridge is full.
BSD-Reference: WD 7
Initial Actions
• Replace the Waste Toner and Toner Cartridges.
• Check for dust covering the sensor window on the cartridge.
Procedure
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer
supply while performing tasks that do not need electricity. Electricity can cause death or
injury. Moving parts can cause injury.
Replace the Waste Toner and Toner Cartridges. The error message is displayed.
YN
Reassemble and perform SCP 6 Final Actions.
Remove the Left Cover (REP 28.3) and check sensor harness connections and condition. The
harness is clean, connected and undamaged.
YN
Repair or reconnect the harness.
Remove the Right Cover (REP 28.2) and reseat CN2 on the MCU Board. The error mes-
sage is displayed.
YN
Reassemble and perform SCP 6 Final Actions.
Replace these components in order until the error is corrected.
1. Waste Toner Full Sensor, PL 9.15 Item 5
2. Joint Board, PL 9.15 Item 7
3. MCU Board, PL 3.10 Item 3
09-590-00 Waste Toner Cartridge Not Installed RAP
09-590-00 The Waste Toner Cartridge Detect Sensor indicates the Waste Toner Cartridge is
not installed.
BSD-Reference: WD 7
Initial Actions
• Check the actuator on the Waste Toner Cartridge Door.
Procedure
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer
supply while performing tasks that do not need electricity. Electricity can cause death or
injury. Moving parts can cause injury.
Check the condition of the actuator on the Waste Toner Cartridge Door. The actuator is
undamaged.
YN
Repair or replace the waste toner cartridge cover, PL 28.10 Item 2
Check the function of the waste toner port on the Waste Toner Cartridge. The port cover
opens when actuated.
YN
Repair of replace the Waste Toner Cartridge.
Remove the Left Cover (REP 28.3) and check sensor harness connections and condition. The
harness is clean, connected and undamaged.
YN
Repair or reconnect the harness.
Remove the Right Cover (REP 28.2) and reseat CN2 on the MCU Board. The error mes-
sage is displayed.
YN
Reassemble and perform SCP 6 Final Actions.
Replace these components in order until the error is corrected.
1. Waste Toner Cartridge Detect Sensor, PL 9.15 Item 6
2. Joint Board, PL 9.15 Item 7
3. MCU Board, PL 3.10 Item 3
